System And Components
513-0170 GEAR & CASE GP-TRANSFERS/N WFR1-UP
Group No: 513-0170
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S3875 | 1 SCREEN-SUCTION | 2 | |
| 6P4903 | 2 PLATE AS | 2 | |
| 7B3028 | SCREW-DRIVE (NO 4X 3/16-IN) | 2 | |
| 7S2962 | WASHER-SPRING (52.3X82.5X9.1-MM THK) | 1 | |
| 8E7003 | 3 SPACER-SPECIAL | 1 | |
| 8S0617 | 4 COVER | 2 | |
| 5130169 | 5 RETAINER | 1 | |
| 1381509 | 6 DRAIN GP-ECOLOGY (POWER TRAIN OIL) | 1 | |
| 2699158 | 7 SEAL-O-RING | 1 | |
| 2714926 | 8 SEAL | 1 | |
| 9W5531 | 9 SCREEN GP-MAGNETIC (TRANSMISSION, TRANSFER GEAR) | 2 | |
| 8M7160 | MAGNET | 5 | |
| 3072673 | 10 PLUG AS | 6 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4545255 | 11 GEAR-INPUT (49-TEETH) | 1 | |
| 4545310 | 12 GEAR-PUMP DRIVE (45-TEETH) | 1 | |
| 4546515 | 13 CAGE-BEARING | 1 | |
| 4546522 | 14 SHAFT-TRANSFER | 1 | |
| 4562263 | 15 COVER | 1 | |
| 4565554 | 16 COVER | 1 | |
| 4566584 | 17 HOUSING-SCREEN | 1 | |
| 4599425 | 18 BALL BEARING | 2 | |
| 4649805 | 19 YOKE AS | 1 | |
| 5130168 | 20 CAGE-BEARING | 1 | |
| 4923948 | 21 CAGE-BEARING | 1 | |
| 4954661 | 22 GEAR-OUTPUT (46-TEETH) | 1 | |
| 4954667 | 23 GEAR-IDLER (41-TEETH) | 1 | |
| 4996390 | 24 SHIM-PACK (INCLUDES 8-SHIMS) | 1 | |
| 5130171 | 25 CASE AS-TRANSFER GEAR | 1 | |
| 5129590 | 26 BEARING AS | 1 | |
| 0617540 | 27 SEAL-O-RING | 1 | |
| 1334296 | 28 SEAL-LIP TYPE | 1 | |
| 1337810 | 29 STUD-TAPERLOCK (M10X1.5X45-MM) | 8 | |
| 1705942 | 30 SEAL-O-RING | 1 | |
| 1P4695 | 31 CUP-BEARING | 2 | |
| 1P4696 | 32 CONE-BEARING | 2 | |
| 1P9269 | 33 COVER | 1 | |
| 2594600 | 34 SEAL-O-RING | 1 | |
| 2J8172 | 35 RING-RETAINING (INTERNAL) | 1 | |
| 4546511 | 36 RETAINER | 2 | |
| 3293356 | 37 NUT (M12X1.75-THD) | 4 | |
| 3346034 | 38 BEARING AS-ROLLER | 2 | |
| 3445675 | 39 NUT (M10X1.5-THD) | 8 | |
| 5H6199 | 40 RING-RETAINING | 1 | |
| 5L5772 | 41 RACE & ROLLER AS | 1 | |
| 5L5773 | 42 RACE-BEARING | 1 | |
| 5P3603 | 43 RING | 1 | |
| 5P5598 | 44 SEAL-O-RING | 1 | |
| 5P8286 | 45 SEAL-O-RING | 3 | |
| 5P8872 | 46 SEAL-O-RING | 1 | |
| 6V1197 | 47 SEAL-O-RING | 2 | |
| 6V5054 | 48 SEAL-O-RING | 1 | |
| 6V7681 | 49 SEAL-O-RING | 1 | |
| 6V8002 | 50 SEAL-O-RING | 1 | |
| 7X2565 | 51 BOLT (M20X2.5X100-MM) | 2 | |
| 8T4121 | 52 WASHER-HARD (11X21X2.5-MM THK) | 30 | |
| 8T4183 | 53 BOLT (M12X1.75X40-MM) | 27 | |
| 8T4194 | 54 BOLT (M12X1.75X50-MM) | 17 | |
| 8T4195 | 55 BOLT (M10X1.5X30-MM) | 12 | |
| 8T4223 | 56 WASHER-HARD (13.5X25.5X3-MM THK) | 51 | |
| 8T5414 | 57 STUD (M12X1.75X50-MM) | 4 | |
| 8T6466 | 58 BOLT (M10X1.5X60-MM) | 18 | |
| 8T6868 | 59 BOLT (M12X1.75X80-MM) | 20 | |
| 6V6640 | SEALANT |
