System And Components
346-3457 LINES GP-FRONT -CMB FCTN, ELEC CONT, ELEC RLFS/N RGP1-UP
Group No: 346-3457
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8J6875 | 1 VALVE GP-SHUTTLE | 1 | |
| 3901478 | 2 HOSE AS | 1 | |
| 2970265 | 3 VALVE GP-SOLENOID & RELIEF (1-WAY, 2-WAY FLOW) | 1 | |
| 3237942 | 4 VALVE GP-SOLENOID & RELIEF (1-WAY, 2-WAY FLOW) | 1 | |
| 3292709 | 5 BLOCK | 1 | |
| 3386971 | 6 SENSOR GP-PRESSURE (HYDRAULIC OIL)(BOOM FLOAT) | 1 | |
| 3476011 | 7 HOSE AS | 1 | |
| 3476018 | 8 SUPPORT | 1 | |
| 3476021 | 9 SUPPORT AS | 1 | |
| 3527064 | 10 CAP | 4 | |
| 3587521 | 11 SUPPORT AS | 1 | |
| 3598378 | 12 HOSE AS | 1 | |
| 3598386 | 13 HOSE AS | 1 | |
| 3917840 | 14 HOSE AS | 1 | |
| 3681710 | 15 SUPPORT AS | 1 | |
| 3740014 | 16 HOSE AS | 1 | |
| 1053483 | 17 BOLT-SOCKET HEAD (M10X1.5X70-MM) | 4 | |
| 1488310 | 18 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8T0151 | ADAPTER | 1 | |
| 1488353 | 19 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488374 | 20 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488378 | 21 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1P3703 | 22 SEAL-RECTANGULAR | 3 | |
| 1P3704 | 23 SEAL-RECTANGULAR | 1 | |
| 1P4577 | 24 FLANGE-HALF | 2 | |
| 1P4578 | 25 FLANGE-HALF | 4 | |
| 1P5767 | 26 FLANGE-HALF | 2 | |
| 4J0520 | 27 SEAL-O-RING | 1 | |
| 4J0522 | 28 SEAL-O-RING | 4 | |
| 5P7462 | 29 CLIP (SLOT) | 1 | |
| 5P7463 | 30 CLIP (TAB) | 1 | |
| 5P7470 | 31 CLIP (SLOT) | 1 | |
| 5P7471 | 32 CLIP (TAB) | 1 | |
| 5P8182 | 33 GROMMET (46-MM ID) | 1 | |
| 6V0400 | 34 FLANGE-HALF | 6 | |
| 6V0683 | 35 GROMMET | 1 | |
| 8T4121 | 36 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4136 | 37 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4184 | 38 BOLT (M12X1.75X45-MM) | 16 | |
| 8T4196 | 39 BOLT (M10X1.5X35-MM) | 12 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 28 | |
| 8T4956 | 41 BOLT (M12X1.75X35-MM) | 12 | |
| 9X2480 | 42 BOLT (M6X1X45-MM) | 2 | |
| 9X8256 | 43 WASHER (6.6X12X2-MM THK) | 2 |
