System And Components
484-6966 LINES GP-PILOT -THIRD PEDAL, PILOT VALVES/N RGP1-UP
Group No: 484-6966
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 4I0800 | 2 HOSE AS | 1 | |
| 4I1878 | 3 HOSE AS | 1 | |
| 4I7889 | 4 SPACER (11X25X45-MM THK) | 2 | |
| 4I9521 | 5 BAND-MARKER (RED, L1) | 2 | |
| 4I9522 | 6 BAND-MARKER (YELLOW, L2) | 2 | |
| 4I9525 | 7 BAND-MARKER (ORANGE, R1) | 2 | |
| 4I9526 | 8 BAND-MARKER (WHITE, R2) | 2 | |
| 7K1181 | 9 STRAP-CABLE | 4 | |
| 7Y5088 | 10 HOSE AS | 1 | |
| 0874402 | 11 HOSE AS | 2 | |
| 1120083 | 12 VALVE GP-SHUTTLE (THIRD PEDAL, STRAIGHT TRAVEL) | 1 | |
| 1335813 | 13 BAND-MARKER (GRAY, P) | 2 | |
| 1488336 | 14 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1504027 | 15 TEE AS | 1 | |
| 3E2310 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1645628 | 16 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1076631 | CONNECTOR-FILTER | 1 | |
| 1681968 | 17 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1266872 | TEE | 1 | |
| 1764768 | 18 HOSE AS | 2 | |
| 3075153 | 19 HOSE AS | 2 | |
| 3527201 | 20 ELBOW AS | 1 | |
| 3D4603 | PLUG-PIPE | 1 | |
| 3E7432 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 4196404 | ELBOW | 1 | |
| 4545075 | 21 SENSOR GP-PRESSURE (STRAIGHT TRAVEL) | 1 | |
| 1488305 | 22 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P9617 | ADAPTER | 1 | |
| 1488353 | 23 ELBOW AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488378 | 24 ELBOW AS | 6 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1503036 | 25 ELBOW AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 1646874 | 26 FITTING AS-ELBOW (QUICK DISCONNECT, MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0857356 | FITTING | 1 | |
| 8T4178 | 27 BOLT (M10X1.5X90-MM) | 2 |
