System And Components
381-2239 LINES GP-FRONT -UNIVERSAL QUICK COUPLERS/N HNG1-UP
Group No: 381-2239
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9521 | 1 BAND-MARKER (RED, L1) | 4 | |
| 4I9522 | 2 BAND-MARKER (YELLOW, L2) | 6 | |
| 4I9525 | 3 BAND-MARKER (ORANGE, R1) | 2 | |
| 1234750 | 4 VALVE AS-CHECK | 1 | |
| 3371327 | 5 BOSS | 1 | |
| 3394353 | 6 VALVE GP-CONTROL (QUICK COUPLER) | 1 | |
| 3839405 | 7 SUPPORT AS | 1 | |
| 3839413 | 8 HOSE AS | 2 | |
| 3839414 | 9 HOSE AS | 1 | |
| 4399070 | 10 HOSE AS | 1 | |
| 4399078 | 11 SUPPORT AS | 1 | |
| 1416348 | 12 BOLT (M10X1.5X65-MM) | 1 | |
| 1488336 | 13 CONNECTOR AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488378 | 14 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1503036 | 15 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 1645546 | 16 TEE AS | 1 | |
| 3E7410 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1645567 | 17 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1646874 | 18 FITTING AS-ELBOW (QUICK DISCONNECT, MALE) | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0857356 | ELBOW-ADAPTER | 1 | |
| 5P7464 | 19 CLIP (SLOT) | 5 | |
| 5P7465 | 20 CLIP (TAB) | 5 | |
| 6V0852 | 21 CAP-DUST | 3 | |
| 6V1249 | 22 GROMMET (22-MM ID) | 5 | |
| 7K1181 | 23 STRAP-CABLE | 5 | |
| 8T3647 | 24 BOLT (M8X1.25X80-MM) | 3 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4136 | 26 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4195 | 27 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4196 | 28 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4224 | 29 WASHER-HARD (8.8X16X2-MM THK) | 3 |
