System And Components
523-5673 LINES GP-FUELS/N YBP1-770
Group No: 523-5673
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4136 | 1 BOLT (M10X1.5X25-MM) | 19 | |
| 8T4182 | 2 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4196 | 3 BOLT (M10X1.5X35-MM) | 4 | |
| 7X2539 | 4 BOLT (M8X1.25X110-MM) | 2 | |
| 8T4198 | 5 BOLT (M10X1.5X100-MM) | 1 | |
| 4I0379 | 7 VALVE-MANUAL (FUEL SHUTOFF) | 1 | |
| 5G3676 | 8 GROMMET | 2 | |
| 5V9155 | 9 CLAMP-HOSE | 1 | |
| 6S8620 | 10 CLAMP-HOSE | 11 | |
| 7I2673 | 11 STRAP-CABLE | 3 | |
| 7V6571 | 12 GROMMET | 1 | |
| 7X0579 | 13 WASHER-HARD (8.8X25.5X2-MM THK) | 3 | |
| 7Y3195 | 14 GROMMET | 3 | |
| 8T1889 | 15 CLIP (SLOT) | 3 | |
| 8T1890 | 16 CLIP (TAB) | 3 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 31 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 6 | |
| 8T6869 | 19 BOLT (M8X1.25X60-MM) | 1 | |
| 8T9655 | 20 MOUNT-ISOLATION | 6 | |
| 1699763 | 21 CONNECTOR | 1 | |
| 1911782 | 22 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 1911783 | 23 SPACER (8.5X12.7X87.3-MM THK) | 2 | |
| 2147568 | 24 SEAL-O-RING | 5 | |
| 2287089 | 25 SEAL-O-RING | 1 | |
| 2751442 | 26 CLIP (TAB) | 2 | |
| 2751443 | 27 CLIP (SLOT) | 2 | |
| 2977964 | 28 CONNECTOR | 2 | |
| 3056873 | 29 SENSOR GP-PRESSURE (FUEL PRIMING PUMP) | 1 | |
| 3133492 | 30 PLUG AS | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3218657 | 31 ELBOW AS | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3295459 | 32 ADAPTER AS | 2 | |
| 5P1404 | ADAPTER | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3474416 | 33 ADAPTER | 2 | |
| 3514319 | 34 CLIP (LOOP) | 9 | |
| 3535142 | 35 ADAPTER AS | 1 | |
| 2198136 | ADAPTER | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3535143 | 36 ADAPTER AS | 1 | |
| 6V5653 | ELBOW (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3686658 | 37 VALVE | 1 | |
| 3794369 | 38 ADAPTER | 1 | |
| 3853821 | 39 GROMMET | 2 | |
| 3906840 | 40 PUMP GP-FUEL PRM & PRIM FILTER | 1 | |
| 4236434 | 41 SENSOR GP-LIQUID LEVEL (WATER IN FUEL) | 1 | |
| 4648596 | 42 ADAPTER-TEE | 1 | |
| 4837801 | 43 SPACER (11X20X15-MM THK) | 1 | |
| 5017449 | 44 ADAPTER AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 5042756 | ADAPTER | 1 | |
| 5173178 | 45 HOSE AS | 1 | |
| 3550632 | CONNECTOR-SPECIAL | 1 | |
| 5239010 | 46 FILTER GP-FUEL | 1 | |
| 5245076 | 47 HOSE AS | 1 | |
| 5245077 | 48 HOSE AS | 1 | |
| 5V9155 | CLAMP-HOSE | 1 | |
| 2643518 | CONNECTOR-RECEPTACLE | 1 | |
| 5245078 | 49 HOSE AS | 1 | |
| 6S8620 | CLAMP-HOSE | 2 | |
| 3550632 | CONNECTOR-SPECIAL | 2 | |
| 5245079 | 50 HOSE AS | 1 | |
| 6S8620 | CLAMP-HOSE | 2 | |
| 3550632 | CONNECTOR-SPECIAL | 2 | |
| 5245085 | 53 PLATE AS | 1 | |
| 9R2672 | BOSS-THREADED (M10X1.5X20-MM) | 2 | |
| 5245086 | 54 PLATE AS | 1 | |
| 2339821 | 57 VALVE AS-CHECK | 1 | |
| 0336042 | SEAL-O-RING | 1 | |
| 3432387 | 58 CLIP (LOOP) | 3 | |
| 3514315 | 59 CLIP (LOOP) | 2 | |
| 3514318 | 60 CLIP (LOOP) | 8 | |
| 3514320 | 61 CLIP (LOOP) | 4 | |
| 3535112 | 62 ADAPTER AS | 1 | |
| 9X0262 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 2 | |
| 4372150 | 63 CLIP (LOOP) | 2 | |
| 7I1024 | 64 GUARD-HOSE (59-CM) | ||
| 3478645 | 65 HOSE (38-CM) | ||
| 3478645 | 65A HOSE (273-CM) | ||
| 3478645 | 65B HOSE (147-CM) | ||
| 3478646 | 66 HOSE (71-CM) | ||
| 3478646 | 66A HOSE (211-CM) | ||
| 3478646 | 66B HOSE (139-CM) | ||
| 7I7439 | 67 GUARD-HOSE (40-CM) | ||
| 7I7439 | 67A GUARD-HOSE (18-CM) | ||
| 0951386 | 68 CLAMP-HOSE | 2 |
