System And Components
441-7205 WIRING GP-CHASSIS -REARS/N LTZ1-UP
Group No: 441-7205
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2662338 | 1 SENSOR GP-POSITION (ROTARY)(TRUCK BODY) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 9X1813 | SLEEVE (17-CM) | ||
| 7K1181 | 2 STRAP-CABLE | 9 | |
| 1258534 | 3 PLATE AS | 1 | |
| 1446302 | 4 BRACKET | 1 | |
| 1580488 | 5 ROD AS | 1 | |
| 5C7261 | NUT (M8X1.25-THD) | 1 | |
| 7X7915 | ROD END | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 1 | |
| 8T6431 | ROD END | 1 | |
| 1580487 | ROD | 1 | |
| 1928959 | 6 BRACKET AS | 1 | |
| 1928961 | 7 BRACKET | 1 | |
| 1984271 | 8 LEVER | 1 | |
| 2048000 | 9 MOUNTING-CABLE TIE | 32 | |
| 2213404 | 10 SENSOR GP-PRESSURE (AUTOMATIC LUBRICATION) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1945226 | TERMINAL AS (16-GA) | 3 | |
| 1945227 | TERMINAL AS (14-GA) | 3 | |
| 2287031 | 11 BRACKET AS | 1 | |
| 2484760 | 12 PLATE | 2 | |
| 3599192 | 13 PLATE | 1 | |
| 3701485 | 14 ALARM GP (BACKUP) | 1 | |
| 4504949 | 15 LAMP GP-SIGNAL (24-VOLT, STOP, TAIL)(LH) | 1 | |
| 4504949 | 15A LAMP GP-SIGNAL (24-VOLT, STOP, TAIL)(RH) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 3E3377 | WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 4704908 | 16 PLATE | 2 | |
| 4704909 | 17 PLATE | 2 | |
| 4792171 | 18 BOLT AS | 10 | |
| 4792172 | 19 BOLT AS | 4 | |
| 4834287 | 20 PLATE | 5 | |
| 4860471 | 21 HARNESS AS-REAR CHASSIS | 1 | |
| 0919035 | 22 SPACER (11X25X20-MM THK) | 1 | |
| 0966166 | 23 WASHER-HARD (4.5X9X1-MM THK) | 8 | |
| 1053487 | 24 BOLT-SOCKET HEAD (M6X1X20-MM) | 1 | |
| 1336934 | 25 SPACER (11X20X25-MM THK) | 6 | |
| 1337810 | 26 STUD-TAPERLOCK (M10X1.5X45-MM) | 1 | |
| 1364184 | 27 BOLT-SOCKET HEAD (M8X1.25X40-MM) | 5 | |
| 1622165 | 28 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 4 | |
| 1984777 | 29 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 2042281 | 30 STRAP-CABLE | 41 | |
| 2147568 | 31 SEAL-O-RING | 1 | |
| 2310336 | 32 STUD-TAPERLOCK (M10X1.5X70-MM) | 5 | |
| 5C8312 | 33 NUT (M4X0.7-THD) | 4 | |
| 3445673 | 34 NUT (M6X1-THD) | 6 | |
| 3445674 | 35 NUT (M8X1.25-THD) | 1 | |
| 3445675 | 36 NUT (M10X1.5-THD) | 14 | |
| 4P7581 | 37 CLIP (LADDER) | 1 | |
| 5P1076 | 38 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 7X2541 | 39 BOLT (M8X1.25X140-MM) | 2 | |
| 7X2543 | 40 BOLT (M10X1.5X120-MM) | 1 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 34 | |
| 8T4137 | 42 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4179 | 43 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4182 | 44 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4185 | 45 BOLT (M10X1.5X50-MM) | 3 | |
| 8T4196 | 46 BOLT (M10X1.5X35-MM) | 5 | |
| 8T4224 | 47 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 8T6466 | 48 BOLT (M10X1.5X60-MM) | 3 | |
| 8T6685 | 49 BOLT (M10X1.5X110-MM) | 1 | |
| 8T7547 | 50 BOLT (M8X1.25X30-MM) | 1 | |
| 9X8256 | 51 WASHER (6.6X12X2-MM THK) | 6 | |
| 2922893 | 52 CONDUIT (10.1-MM ID)(15-CM EACH) |
