System And Components
465-9474 WIRING GP-CHASSISS/N LTZ144-UP
Group No: 465-9474
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4242316 | 1 BLOCK | 10 | |
| 4242322 | 2 BLOCK | 10 | |
| 4242325 | 3 BLOCK | 3 | |
| 4242331 | 4 BLOCK | 10 | |
| 4242335 | 5 BLOCK | 14 | |
| 4242342 | 6 BLOCK | 6 | |
| 7K1181 | 8 STRAP-CABLE | 2 | |
| 1446302 | 9 BRACKET | 2 | |
| 2048000 | 10 MOUNTING-CABLE TIE | 44 | |
| 2435821 | 11 BRACKET AS | 1 | |
| 2744478 | 13 CABLE AS (VIDEO, 11-M) | 1 | |
| 2790478 | 14 HARNESS AS-CHASSIS (SENSORS, SOLENOIDS) | 1 | |
| 2888390 | 15 SENSOR GP-TEMPERATURE (TORQUE CONVERTER OIL) | 1 | |
| 2905562 | 16 MOUNT (DUAL SWIVEL) | 1 | |
| 3203061 | 17 SENSOR GP-PRESSURE (OUTPUT MODULE) | 1 | |
| 3413797 | 20 PLATE AS | 1 | |
| 3413798 | 21 PLATE AS | 1 | |
| 3464324 | 22 PLATE | 1 | |
| 3524203 | 23 STRAP-CABLE | 2 | |
| 4218019 | 24 BRACKET AS | 1 | |
| 4242350 | 25 PLATE AS | 5 | |
| 4242352 | 26 PLATE | 5 | |
| 4242353 | 27 PLATE AS | 5 | |
| 4242352 | PLATE | 1 | |
| 4242358 | 28 PLATE | 5 | |
| 4242373 | 29 PLATE | 5 | |
| 4381631 | 33 PLATE AS | 2 | |
| 4381634 | 34 PLATE | 2 | |
| 4455754 | 35 WIRE AS | 2 | |
| 4659475 | 36 HARNESS AS-CHASSIS (ENGINE INTERFACE) | 1 | |
| 4690008 | 37 HARNESS AS-CHASSIS (REAR) | 1 | |
| 4708496 | 38 BRACKET AS | 1 | |
| 4708497 | 39 BRACKET AS | 1 | |
| 4792171 | 40 BOLT AS | 28 | |
| 4792172 | 41 BOLT AS | 15 | |
| 4819783 | 42 HARNESS AS-CHASSIS (TRANSMISSION) | 1 | |
| 4834287 | 43 PLATE | 16 | |
| 4900663 | 44 INDICATOR AS-PRESSURE (BRAKE OIL FILTER) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 4512763 | SEAL | 1 | |
| 0910081 | 46 SPACER (10.5X20X10-MM THK) | 1 | |
| 0919035 | 47 SPACER (11X25X20-MM THK) | 1 | |
| 0993649 | 48 BOLT (M8X1.25X40-MM) | 1 | |
| 1046202 | 49 CLIP (LADDER) | 1 | |
| 1325789 | 50 CLIP (LADDER) | 1 | |
| 1336934 | 51 SPACER (11X20X25-MM THK) | 11 | |
| 1337810 | 52 STUD-TAPERLOCK (M10X1.5X45-MM) | 1 | |
| 1361122 | 53 SPACER (13.8X25X10-MM THK) | 1 | |
| 1364992 | 54 SPACER (11X20X40-MM THK) | 2 | |
| 1984777 | 55 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 2042281 | 56 STRAP-CABLE | 94 | |
| 2147568 | 57 SEAL-O-RING | 1 | |
| 2284710 | 58 SPACER (13.8X30X20-MM THK) | 2 | |
| 2307732 | 59 MOUNTING-CABLE TIE | 12 | |
| 2310336 | 60 STUD-TAPERLOCK (M10X1.5X70-MM) | 15 | |
| 2597140 | 61 STUD-TAPERLOCK (M10X1.5X80-MM) | 3 | |
| 2812592 | 62 PIN-TAPERLOCK | 1 | |
| 2884402 | 63 STUD-TAPERLOCK (M10X1.5X60-MM) | 2 | |
| 2887158 | 64 STUD (M10X1.5X125-MM) | 1 | |
| 2939452 | 65 MOUNTING-CABLE TIE | 1 | |
| 3023908 | 66 SPACER (11X20X30-MM THK) | 4 | |
| 3091905 | 67 STUD-TAPERLOCK (M10X1.5X100-MM) | 1 | |
| 3160488 | 68 SPACER (11X25X78-MM THK) | 1 | |
| 3445675 | 69 NUT (M10X1.5-THD) | 31 | |
| 3453753 | 70 MOUNTING-CABLE TIE | 1 | |
| 3812621 | 71 MOUNTING-CABLE TIE | 2 | |
| 4S1962 | 72 CLIP (LOOP) | 1 | |
| 5P1076 | 73 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P7468 | 74 CLIP (SLOT) | 4 | |
| 5P7469 | 75 CLIP (TAB) | 4 | |
| 5P7470 | 76 CLIP (SLOT) | 1 | |
| 5P7471 | 77 CLIP (TAB) | 1 | |
| 5P7703 | 78 GROMMET (52-MM ID) | 1 | |
| 5P8444 | 79 GROMMET (37-MM ID) | 3 | |
| 6V1249 | 80 GROMMET (22-MM ID) | 1 | |
| 6V7357 | 81 BOLT (M6X1X25-MM) | 4 | |
| 6W7636 | 82 SPACER (11.13X19.05X30-MM THK) | 1 | |
| 7X7729 | 83 WASHER (11X25X3-MM THK) | 1 | |
| 8M2770 | 84 CLIP (LOOP) | 1 | |
| 8T1899 | 85 CLIP (SLOT) | 1 | |
| 8T1900 | 86 CLIP (TAB) | 1 | |
| 8T4121 | 87 WASHER-HARD (11X21X2.5-MM THK) | 59 | |
| 8T4137 | 88 BOLT (M10X1.5X20-MM) | 8 | |
| 8T4179 | 90 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4183 | 91 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4185 | 92 BOLT (M10X1.5X50-MM) | 9 | |
| 8T4186 | 93 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4196 | 94 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4198 | 95 BOLT (M10X1.5X100-MM) | 1 | |
| 8T4223 | 96 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4224 | 97 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T4956 | 98 BOLT (M12X1.75X35-MM) | 1 | |
| 8T5005 | 99 BOLT (M10X1.5X70-MM) | 1 | |
| 8T6466 | 100 BOLT (M10X1.5X60-MM) | 5 | |
| 8T7087 | 101 GROMMET (34-MM ID) | 1 | |
| 9X8256 | 102 WASHER (6.6X12X2-MM THK) | 4 | |
| 1F1609 | 103 SPACER (13.5X25.4X39.7-MM THK) | 1 | |
| 8T4176 | 104 BOLT (M12X1.75X90-MM) | 1 | |
| 1327551 | 105 SPACER (11X19X6-MM THK) | 1 | |
| 1928960 | 106 BRACKET | 1 | |
| 5302559 | 107 HARNESS AS-ENGINE | 1 | |
| 5334159 | 108 BOLT AS | 1 | |
| 4J6303 | 109 TAG-IDENTIFICATION (NUMBER THREE) | 1 |
