System And Components
Assembly
100%

324-2716 PUMP GP-GEARS/N LTZ1-UP

Group No: 324-2716
Part NumberPart NameQty
6I90561 GEAR (12-TEETH)2
15144033 COVER AS1
15981743A BUSHING2
8M84893B DOWEL2
15144154 BODY-OIL PUMP1
15144575 COVER AS1
15981735A BUSHING2
8M84895B DOWEL2
15144596 BODY AS-OIL PUMP1
8M84896A DOWEL4
15144667 COVER AS1
6P32237A DAMPER-BOLT2
9M06697B DOWEL2
15981747C BUSHING2
15144718 GEAR (8-TEETH)1
15368439 BODY AS-OIL PUMP1
6P32239A DAMPER-BOLT4
8M84899B DOWEL2
5M33209C BUSHING2
167131510 GEAR (8-TEETH)2
167691311 GEAR (8-TEETH)1
324271712 ADAPTER-OIL PUMP1
061945814 SEAL-O-RING6
161806815 SEAL-O-RING5
161806916 SEAL-O-RING1
1B873617 KEY-WOODRUFF2
228710318 SEAL-O-RING1
2D641619 WASHER (0.438X1.25X0.12-IN THK)1
3E233120 PLUG (M18X1.5-THD)1
3S000421 WASHER (0.406X0.728X0.09-IN THK)8
7X047422 BOLT (M10X1.5X220-MM)4
7X254723 BOLT (M10X1.5X200-MM)2
8T419624 BOLT (M10X1.5X35-MM)3
