System And Components
461-6675 LINES GP-STEERINGS/N ST71-UP
Group No: 461-6675
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2T3000 | 1 FLANGE-SPLIT | 6 | |
| 6V3482 | 2 CAP AS | 1 | |
| 1358575 | 3 BOLT AS | 2 | |
| 1608708 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1645567 | 5 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1925806 | 6 BRACKET | 1 | |
| 2067013 | 7 FASTENER | 82 | |
| 2815932 | 8 TEE AS | 1 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 3072673 | 9 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196217 | 10 CONNECTOR AS | 3 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3855772 | 11 ELBOW AS | 1 | |
| 6V8628 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3960393 | 12 PLUG AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 4316083 | 13 FILTER GP-OIL (HYDRAULIC) | 1 | |
| 4329443 | 14 PLATE | 1 | |
| 4350692 | 15 PLATE-COVER | 12 | |
| 4356712 | 16 PLATE-LOCK | 1 | |
| 4357022 | 17 PLATE-COVER | 2 | |
| 4386500 | 18 BOLT (M10X1.5X40-MM) | 2 | |
| 4391826 | 19 CONNECTOR AS | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 4423532 | 20 ADAPTER AS | 4 | |
| 8T7946 | REDUCER-ORFS | 1 | |
| 9X6577 | NUT | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 4423533 | 21 ADAPTER AS | 3 | |
| 2124991 | ADAPTER-TEE | 1 | |
| 2287095 | SEAL-O-RING | 2 | |
| 2385086 | SEAL-O-RING | 1 | |
| 4423535 | 22 ADAPTER AS | 2 | |
| 8T8552 | REDUCER-ORFS | 1 | |
| 9X6577 | NUT | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 4491413 | 23 ADAPTER AS | 1 | |
| 6V8556 | NUT (1-3/16-12-THD) | 1 | |
| 6V8942 | REDUCER-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 4616676 | 24 BRACKET AS | 2 | |
| 4327911 | RAIL-MOUNTING (96-CM) | ||
| 4616678 | 25 BRACKET AS | 1 | |
| 4327911 | RAIL-MOUNTING (93-CM) | ||
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 3 | |
| 4616683 | 26 PLATE | 1 | |
| 4616684 | 27 HOSE AS | 2 | |
| 4616687 | 28 HOSE AS | 1 | |
| 4616688 | 29 HOSE AS | 1 | |
| 4616689 | 30 HOSE AS | 1 | |
| 4616690 | 31 HOSE AS | 1 | |
| 4616691 | 32 HOSE AS | 1 | |
| 4616693 | 33 HOSE AS | 1 | |
| 4616695 | 34 HOSE AS | 1 | |
| 4616696 | 35 HOSE AS | 1 | |
| 4616697 | 36 HOSE AS | 1 | |
| 4616736 | 37 HOSE AS | 1 | |
| 4616737 | 38 HOSE AS | 1 | |
| 4616742 | 39 HOSE AS | 1 | |
| 4635928 | 40 HOSE AS | 1 | |
| 4669521 | 41 BRACKET AS | 1 | |
| 4327911 | RAIL-MOUNTING (68-CM) | ||
| 4689700 | 42 CLAMP-HALF | 12 | |
| 4689708 | 43 CLAMP-HALF | 4 | |
| 4727058 | 44 FILTER AS-OIL (HYDRAULIC STEERING) | 2 | |
| 4176162 | FILTER-OIL (HYDRAULIC) | 1 | |
| 4538935 | COVER AS-FILTER (CARTRIDGE, OIL) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603692 | PLUG (9/16-18-THD) | 1 | |
| 4883974 | 45 BOLT AS | 6 | |
| 5175448 | 46 CLAMP-HALF | 24 | |
| 5175505 | 47 CLAMP-HALF | 12 | |
| 5175530 | 48 CLAMP-HALF | 30 | |
| 0672551 | 49 CLIP | 1 | |
| 1358573 | 50 BOLT AS | 7 | |
| 1497738 | 51 CLIP (LOOP) | 1 | |
| 1705715 | 52 SEAL-O-RING | 4 | |
| 1731437 | 53 FLANGE-HALF | 4 | |
| 1912962 | 54 SEAL-O-RING | 2 | |
| 1984781 | 55 WASHER-HARD (22X40X10-MM THK) | 2 | |
| 1P4577 | 56 FLANGE-HALF | 2 | |
| 1P4579 | 57 FLANGE-HALF | 2 | |
| 1P5767 | 58 FLANGE-HALF | 2 | |
| 1S0994 | 59 CLIP (LOOP) | 1 | |
| 2287088 | 60 SEAL-O-RING | 1 | |
| 2343544 | 61 SEAL-O-RING | 4 | |
| 2352475 | 62 SEAL-RECTANGULAR | 1 | |
| 2352476 | 63 SEAL-RECTANGULAR | 1 | |
| 2815972 | 64 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2815982 | 65 CONNECTOR AS | 1 | |
| 6V9874 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2977968 | 66 FITTING | 1 | |
| 3218619 | 67 TEE AS | 1 | |
| 1021384 | TEE-FACE SEAL | 1 | |
| 2287092 | SEAL-O-RING | 2 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3293356 | 68 NUT (M12X1.75-THD) | 1 | |
| 3295518 | 69 ADAPTER AS | 2 | |
| 8T2353 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3295537 | 70 CONNECTOR AS | 1 | |
| 6Y2349 | CONNECTOR | 1 | |
| 2385082 | SEAL-O-RING | 2 | |
| 3309758 | 71 ELBOW AS | 1 | |
| 8T4149 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3445675 | 72 NUT (M10X1.5-THD) | 4 | |
| 3696871 | 73 CONNECTOR AS | 2 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 3696870 | ADAPTER-ELBOW | 1 | |
| 3B4505 | 74 LOCKWASHER | 2 | |
| 3G8047 | 75 GROMMET | 1 | |
| 3G8054 | 76 CLIP (TAB) | 1 | |
| 3G8057 | 77 CLIP (SLOT) | 1 | |
| 4357441 | 78 PLATE-COVER | 26 | |
| 4580318 | 79 VALVE GP-STEERING | 1 | |
| 4616698 | 80 BRACKET AS | 3 | |
| 4327911 | RAIL-MOUNTING (96-CM) | ||
| 4653652 | 81 HOSE AS | 1 | |
| 4792171 | 82 BOLT AS | 3 | |
| 4792172 | 83 BOLT AS | 2 | |
| 4D9517 | 84 CLIP | 1 | |
| 5692102 | 85 HOSE AS | 1 | |
| 5692103 | 86 HOSE AS | 1 | |
| 5716253 | 87 MANIFOLD GP-CONTROL | 1 | |
| 5H4020 | 88 COVER | 1 | |
| 6C3241 | 89 BOLT (1/2-13X1.5-IN) | 8 | |
| 5P7466 | 90 CLIP (SLOT) | 1 | |
| 5P7467 | 91 CLIP (TAB) | 1 | |
| 5P7468 | 92 CLIP (SLOT) | 2 | |
| 5P7469 | 93 CLIP (TAB) | 2 | |
| 5P8077 | 94 FLANGE-HALF | 2 | |
| 5P8112 | 95 GROMMET | 1 | |
| 5P8444 | 96 GROMMET (37-MM ID) | 2 | |
| 5S7382 | 97 BOLT (3/8-16X1.375-IN) | 4 | |
| 6V0852 | 98 CAP-DUST | 2 | |
| 6V1572 | 99 CLIP (SLOT) | 3 | |
| 6V1573 | 100 CLIP (TAB) | 3 | |
| 6V1875 | 101 GROMMET | 3 | |
| 7X2444 | 102 TEE-SWIVEL | 1 | |
| 7X3392 | 103 WASHER-HARD (13.5X22.5X3-MM THK) | 8 | |
| 7X7729 | 104 WASHER (11X25X3-MM THK) | 5 | |
| 8C3206 | 105 FLANGE-HALF | 6 | |
| 8T4121 | 106 WASHER-HARD (11X21X2.5-MM THK) | 96 | |
| 8T4122 | 107 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 8T4140 | 108 BOLT (M16X2X60-MM) | 4 | |
| 8T4182 | 109 BOLT (M10X1.5X45-MM) | 24 | |
| 8T4186 | 110 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4192 | 111 BOLT (M12X1.75X25-MM) | 13 | |
| 8T4194 | 112 BOLT (M12X1.75X50-MM) | 5 | |
| 1837121 | 113 BOLT (M10X1.5X35-MM) | 15 | |
| 8T4223 | 114 WASHER-HARD (13.5X25.5X3-MM THK) | 27 | |
| 8T4896 | 115 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T4956 | 116 BOLT (M12X1.75X35-MM) | 8 | |
| 8T5005 | 117 BOLT (M10X1.5X70-MM) | 5 | |
| 8T6466 | 118 BOLT (M10X1.5X60-MM) | 51 | |
| 8T6871 | 119 BOLT (5/8-11X2.5-IN) | 12 | |
| 8T9043 | 120 BOLT (5/16-18X0.875-IN) | 2 |
