465-6337 LINES GP-STEERINGS/N ST71-UP

Group No: 465-6337

Part Number	Part Name	Qty
1923897	1 PUMP GP-METERING (HMU)	1
2067013	2 FASTENER	6
3196217	3 CONNECTOR AS	2
6V8639	CONNECTOR	1
2287090	SEAL-O-RING	1
2385080	SEAL-O-RING	1
3295473	4 UNION AS	2
6V8997	UNION	1
2287092	SEAL-O-RING	2
3309774	5 UNION AS	1
6V8995	UNION (STRAIGHT)	1
2287090	SEAL-O-RING	2
3960376	6 ADAPTER AS	1
6V8993	UNION	1
2287088	SEAL-O-RING	2
4315111	7 HOSE AS	1
4329368	8 ADAPTER AS	1
6V8780	TEE	1
2147566	SEAL-O-RING	1
2287088	SEAL-O-RING	2
4356712	9 PLATE-LOCK	2
4386500	10 BOLT (M10X1.5X40-MM)	4
4616723	11 BRACKET AS	1
4656336	12 PLATE	1
4689671	13 CLAMP-HALF	2
5175448	14 CLAMP-HALF	4
5175530	15 CLAMP-HALF	4
5245549	16 COVER AS	1
5266972	17 HOSE AS	1
5266973	18 HOSE AS	1
5277380	19 HOSE AS	1
5277381	20 HOSE AS	1
5277382	21 HOSE AS	1
5277383	22 HOSE AS	1
1984777	23 WASHER-HARD (11X25X10-MM THK)	1
2815982	24 CONNECTOR AS	1
6V9874	CONNECTOR	1
2287092	SEAL-O-RING	1
2385080	SEAL-O-RING	1
2P1279	25 LOCKNUT (9/16-18-THD)	1
2P1293	26 LOCKNUT (1-3/16-12-THD)	2
2V1771	27 GROMMET	1
3039449	28 STUD (M10X1.5-THD)	1
3295526	29 UNION AS	2
6V8996	UNION	1
2287091	SEAL-O-RING	2
3309759	30 TEE AS	1
4I7651	TEE-O-RING PORT	1
2287090	SEAL-O-RING	1
2287092	SEAL-O-RING	1
2385080	SEAL-O-RING	1
3445675	31 NUT (M10X1.5-THD)	1
4357441	32 PLATE-COVER	3
4K8864	33 CLIP (LOOP)	1
5M3062	34 BOLT (3/8-16X0.75-IN)	1
5P1076	35 WASHER-HARD (13.5X30X4-MM THK)	2
6V9169	36 NUT (13/16-16-THD)	1
6V9170	37 NUT-BULKHEAD (1-14-THD)	2
7X7729	38 WASHER (11X25X3-MM THK)	5
8T1160	39 BOLT-SOCKET HEAD (M10X1.5X50-MM)	4
8T1887	40 CLIP (SLOT)	1
8T1888	41 CLIP (TAB)	1
8T4121	42 WASHER-HARD (11X21X2.5-MM THK)	11
8T4136	43 BOLT (M10X1.5X25-MM)	5
8T4192	44 BOLT (M12X1.75X25-MM)	2
8T4896	45 WASHER-HARD (10.2X18.5X2.5-MM THK)	1
8T6466	46 BOLT (M10X1.5X60-MM)	5
