Assembly
100%

515-2174 SUPPORT GP-RADIATORS/N N951-UP

Group No: 515-2174
Part NumberPart NameQty
18987891 BUMPER AS2
32855912 BLOCK2
34117653 PLATE AS1
8T3490NUT-WELD (M10X1.5-THD)2
34117684 PLATE2
34117705 PLATE2
38067876 BRACKET1
38067887 BRACKET1
43633618 PLATE AS1
8T3490NUT-WELD (M10X1.5-THD)3
8T3597NUT-WELD (M12X1.75-THD)2
3558941NUT-WELD (M16X2-THD)4
51945099 PLATE AS1
8T3612NUT-WELD (M8X1.25-THD)4
3558941NUT-WELD (M16X2-THD)6
519451110 PLATE AS1
8T3490NUT-WELD (M10X1.5-THD)2
3558941NUT-WELD (M16X2-THD)3
525856111 PLATE AS1
8T3490NUT-WELD (M10X1.5-THD)11
8T3612NUT-WELD (M8X1.25-THD)2
544294612 PLATE AS1
8T3490NUT-WELD (M10X1.5-THD)16
8T3612NUT-WELD (M8X1.25-THD)4
039855713 WASHER (13X26X6-MM THK)2
129318014 LOCKNUT (M12X1.75-THD)4
198477715 WASHER-HARD (11X25X10-MM THK)6
198477816 WASHER-HARD (13.5X30X12-MM THK)4
198478017 WASHER-HARD (17.5X32X8-MM THK)16
267350718 WASHER-HARD (26X47X12-MM THK)4
328185119 STRIKER AS1
3T085220 LOCKNUT (M8X1.25-THD)4
519451321 PLATE AS1
3558941NUT-WELD (M16X2-THD)3
5C726122 NUT (M8X1.25-THD)2
5P411623 WASHER-HARD (8.8X20.5X2-MM THK)4
7X255324 BOLT (M16X2X40-MM)14
7X257625 BOLT (M24X3X70-MM)4
7X772926 WASHER (11X25X3-MM THK)2
8T412127 WASHER-HARD (11X21X2.5-MM THK)4
8T413628 BOLT (M10X1.5X25-MM)2
8T418429 BOLT (M12X1.75X45-MM)4
8T419530 BOLT (M10X1.5X30-MM)4
8T419631 BOLT (M10X1.5X35-MM)6
8T691232 BOLT (M8X1.25X50-MM)4
8T733833 BOLT (M16X2X45-MM)2
