System And Components
388-0296 LINES GP-PILOT -CONTROL VALVES/N WYA1-UP
Group No: 388-0296
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0818 | 1 HOSE AS | 1 | |
| 4I3981 | 2 HOSE AS | 1 | |
| 4I9521 | 3 BAND-MARKER (RED, L1) | 2 | |
| 4I9522 | 4 BAND-MARKER (YELLOW, L2) | 2 | |
| 4I9524 | 5 BAND-MARKER (BROWN, L4) | 2 | |
| 4I9525 | 6 BAND-MARKER (ORANGE, R1) | 2 | |
| 4I9527 | 7 BAND-MARKER (GREEN, R3) | 2 | |
| 4I9528 | 8 BAND-MARKER (PURPLE, R4) | 2 | |
| 0875780 | 9 HOSE AS | 1 | |
| 1158645 | 10 GUARD | 1 | |
| 1504044 | 11 CONNECTOR AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1779 | CONNECTOR | 1 | |
| 2686850 | 12 HOSE AS | 1 | |
| 3237659 | 13 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3237660 | PLUG-STOP | 1 | |
| 3337211 | 14 HOSE AS | 1 | |
| 3372572 | 15 GROMMET | 1 | |
| 3514985 | 16 HOSE AS | 1 | |
| 3514986 | 17 HOSE AS | 1 | |
| 3632459 | 18 HOSE AS | 1 | |
| 1488353 | 20 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488378 | 21 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488435 | 22 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8781 | TEE | 1 | |
| 1503036 | 23 ELBOW AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 1504027 | 24 TEE AS | 1 | |
| 3E2310 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 7K1181 | 25 STRAP-CABLE | 5 |
