System And Components
556-4146 LINES GP-POWER TRAIN OILS/N RJZ1-UP
Group No: 556-4146
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D4202 | 1 PLATE | 1 | |
| 7H1447 | 2 CAP-FILLER (POWER TRAIN) | 1 | |
| 7K1181 | 3 STRAP-CABLE | 4 | |
| 8X4886 | 4 ELBOW | 1 | |
| 9C4937 | 5 BREATHER AS (TORQUE CONVERTER, TRANSMISSION) | 1 | |
| 9N1909 | 6 BRACKET | 1 | |
| 1369699 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1414007 | 8 SLEEVE | 1 | |
| 1973295 | 9 FLANGE-HALF | 2 | |
| 2006345 | 10 SADDLE-MOUNTING (DUAL SWIVEL) | 2 | |
| 2343544 | 11 SEAL-O-RING | 7 | |
| 2875279 | 12 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3196218 | 13 ELBOW AS | 1 | |
| 6V9002 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196220 | 14 ELBOW AS | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3295528 | 15 ELBOW AS | 1 | |
| 8T8899 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 3340032 | 16 HOSE AS | 1 | |
| 3408731 | 17 HOSE AS | 1 | |
| 3441876 | 18 TUBE AS | 1 | |
| 3465571 | 19 FILTER GP-OIL (HYDRAULIC, TRANSMISSION) | 1 | |
| 3478785 | 20 HOSE AS | 1 | |
| 3481783 | 21 COVER | 1 | |
| 3524872 | 22 HOSE AS | 1 | |
| 3625989 | 23 TUBE AS | 1 | |
| 3626068 | 24 TUBE AS | 1 | |
| 3637787 | 25 HOSE AS | 1 | |
| 3866044 | 26 TUBE AS | 1 | |
| 3866045 | 27 TUBE AS | 1 | |
| 3869871 | 28 HOSE AS | 1 | |
| 3877104 | 29 TUBE AS | 1 | |
| 3877105 | 30 TUBE AS | 1 | |
| 3877106 | 31 GAUGE-OIL (POWER TRAIN) | 1 | |
| 0308324 | 32 ELBOW | 1 | |
| 0919035 | 33 SPACER (11X25X20-MM THK) | 1 | |
| 1091633 | 34 CLIP (SLOT) | 1 | |
| 1091634 | 35 CLIP (TAB) | 1 | |
| 1488443 | 36 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 7X2459 | ADAPTER-TEE | 1 | |
| 1645567 | 37 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1757963 | 38 CONNECTOR | 1 | |
| 5T6374 | 39 SPACER (11X20X40-MM THK) | 1 | |
| 1984777 | 40 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 1P4578 | 41 FLANGE-HALF | 4 | |
| 1P4579 | 42 FLANGE-HALF | 12 | |
| 1P4582 | 43 FLANGE-HALF | 4 | |
| 2287090 | 44 SEAL-O-RING | 1 | |
| 2287092 | 45 SEAL-O-RING | 2 | |
| 2287094 | 46 SEAL-O-RING | 2 | |
| 2310336 | 47 STUD-TAPERLOCK (M10X1.5X70-MM) | 1 | |
| 2352476 | 48 SEAL-RECTANGULAR | 1 | |
| 2352479 | 49 SEAL-RECTANGULAR | 1 | |
| 2352480 | 50 SEAL-RECTANGULAR | 2 | |
| 2385082 | 51 SEAL-O-RING | 1 | |
| 2597140 | 52 STUD-TAPERLOCK (M10X1.5X80-MM) | 1 | |
| 3023908 | 53 SPACER (11X20X30-MM THK) | 1 | |
| 3091905 | 54 STUD-TAPERLOCK (M10X1.5X100-MM) | 1 | |
| 3196225 | 55 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218649 | 56 VALVE AS-FLUID SAMPLING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3218654 | 57 ADAPTER AS | 2 | |
| 3P1932 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3295521 | 58 TEE AS | 1 | |
| 1096511 | TEE-O-RING | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3445675 | 59 NUT (M10X1.5-THD) | 10 | |
| 3625995 | 60 HOSE AS | 1 | |
| 3632932 | 61 HOSE AS | 1 | |
| 3B7743 | 62 FITTING | 1 | |
| 3E6909 | 63 CLIP (LOOP) | 2 | |
| 3F5792 | 64 SEAL-O-RING | 1 | |
| 4504553 | 65 HOSE AS | 1 | |
| 4766562 | 66 TUBE AS | 1 | |
| 4910882 | 67 HOSE AS | 1 | |
| 4D3734 | 68 ELBOW | 1 | |
| 4D4917 | 69 TEE | 1 | |
| 4J0520 | 70 SEAL-O-RING | 1 | |
| 4J0522 | 71 SEAL-O-RING | 4 | |
| 4J0525 | 72 SEAL-O-RING | 1 | |
| 4J0527 | 73 SEAL-O-RING | 2 | |
| 4L6459 | 74 BOLT (3/8-16X2.5-IN) | 4 | |
| 5582559 | 75 BRACKET | 1 | |
| 5599843 | 76 BRACKET | 1 | |
| 5P7466 | 77 CLIP (SLOT) | 1 | |
| 5P7467 | 78 CLIP (TAB) | 1 | |
| 5P7468 | 79 CLIP (SLOT) | 3 | |
| 5P7469 | 80 CLIP (TAB) | 3 | |
| 5P7470 | 81 CLIP (SLOT) | 6 | |
| 5P7471 | 82 CLIP (TAB) | 6 | |
| 5P7703 | 83 GROMMET (52-MM ID) | 5 | |
| 5P8112 | 84 GROMMET | 1 | |
| 5P8182 | 85 GROMMET (46-MM ID) | 1 | |
| 5P8444 | 86 GROMMET (37-MM ID) | 1 | |
| 6D4246 | 87 CLIP (LOOP) | 1 | |
| 5P1293 | 88 HOSE (13-CM) | ||
| 6V0545 | 89 GROMMET | 2 | |
| 6V0852 | 90 CAP-DUST | 2 | |
| 6V1867 | 91 CLIP (SLOT) | 1 | |
| 6V1868 | 92 CLIP (TAB) | 1 | |
| 6V1869 | 93 GROMMET (65-MM ID) | 1 | |
| 6V8942 | 94 REDUCER-O-RING | 1 | |
| 7D1553 | 95 CLIP | 2 | |
| 7S8920 | 96 CLIP (SLOT) | 2 | |
| 7S8921 | 97 CLIP (TAB) | 2 | |
| 7X0311 | 98 BOLT (7/16-14X2.25-IN) | 2 | |
| 7X0314 | 99 BOLT (7/16-14X3-IN) | 2 | |
| 7X2550 | 100 BOLT (M12X1.75X110-MM) | 4 | |
| 7X3392 | 101 WASHER-HARD (13.5X22.5X3-MM THK) | 8 | |
| 7X7729 | 102 WASHER (11X25X3-MM THK) | 8 | |
| 8C3447 | 103 CAP-DUST | 1 | |
| 8M4433 | 104 SEAL-O-RING | 2 | |
| 8S0023 | 105 CLIP (SLOT) | 2 | |
| 8S0024 | 106 CLIP (TAB) | 2 | |
| 8S0948 | 107 CLIP | 2 | |
| 8S9009 | 108 ELBOW | 1 | |
| 8T2275 | 109 BALL | 1 | |
| 8T4121 | 110 WASHER-HARD (11X21X2.5-MM THK) | 38 | |
| 8T4136 | 111 BOLT (M10X1.5X25-MM) | 13 | |
| 8T4137 | 112 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4176 | 113 BOLT (M12X1.75X90-MM) | 2 | |
| 8T4182 | 114 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4183 | 115 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 116 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4186 | 117 BOLT (M10X1.5X40-MM) | 10 | |
| 8T4194 | 118 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4195 | 119 BOLT (M10X1.5X30-MM) | 6 | |
| 8T4196 | 120 BOLT (M10X1.5X35-MM) | 6 | |
| 8T4223 | 121 WASHER-HARD (13.5X25.5X3-MM THK) | 52 | |
| 8T4648 | 122 BOLT (M12X1.75X70-MM) | 1 | |
| 8T4835 | 123 BOLT (1/2-13X2-IN) | 4 | |
| 8T4896 | 124 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T4910 | 125 BOLT (M12X1.75X60-MM) | 3 | |
| 8T4956 | 126 BOLT (M12X1.75X35-MM) | 4 | |
| 8T5041 | 127 BOLT (M12X1.75X120-MM) | 2 | |
| 8T6703 | 128 CLAMP-HOSE | 2 | |
| 8T8919 | 129 BOLT (1/2-13X1.75-IN) | 12 | |
| 8T9391 | 130 BOLT (1/2-13X3.75-IN) | 8 | |
| 9D6196 | 131 CLIP (SLOT) | 2 | |
| 9D6197 | 132 CLIP (TAB) | 2 | |
| 9H6454 | 133 GASKET | 1 | |
| 9L2662 | 134 GASKET | 1 | |
| 9X6580 | 135 NUT (1-3/16-12-THD) | 1 |
