System And Components
545-7100 RADIATOR GPS/N E4W1-UP
Group No: 545-7100
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V3251 | 1 SEAL-O-RING | 6 | |
| 5P1076 | 2 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 6I2635 | 3 HOSE-RADIATOR | 8 | |
| 7X0594 | 4 WASHER-HARD (20X38X3-MM THK) | 32 | |
| 7X7729 | 5 WASHER (11X25X3-MM THK) | 100 | |
| 0919035 | 6 SPACER (11X25X20-MM THK) | 8 | |
| 1213307 | 7 MOUNT AS-RESILIENT | 16 | |
| 1849114 | 8 ELBOW | 2 | |
| 1957930 | 9 CONNECTOR | 2 | |
| 4489007 | 10 ADAPTER-ELBOW | 2 | |
| 5457093 | 11 CHANNEL AS (RH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 16 | |
| 5457094 | 12 CHANNEL AS-TOP | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 3558941 | NUT-WELD (M16X2-THD) | 1 | |
| 5457095 | 13 CHANNEL AS (LH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 12 | |
| 5457096 | 14 CHANNEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 5457097 | 15 CHANNEL AS (RH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 12 | |
| 5457098 | 16 CHANNEL AS-TOP | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 14 | |
| 3558941 | NUT-WELD (M16X2-THD) | 1 | |
| 5457099 | 17 BRACKET AS | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 4 | |
| 3558941 | NUT-WELD (M16X2-THD) | 2 | |
| 5457104 | 18 TANK GP-COOLANT | 1 | |
| 0672935 | FITTING-PIPE | 4 | |
| 2874790 | GAUGE-SIGHT | 4 | |
| 2943342 | CAP-RADIATOR | 2 | |
| 5457103 | TANK AS-COOLANT | 1 | |
| 5457105 | 19 TUBE AS | 4 | |
| 5457156 | 20 CORE AS-RADIATOR | 2 | |
| 5457157 | 21 CORE AS-RADIATOR | 2 | |
| 5492885 | 22 CHANNEL AS (LH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 16 | |
| 5492886 | 23 CHANNEL-BOTTOM | 1 | |
| 5588446 | 24 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 5588447 | 25 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 5588448 | 26 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 14 | |
| 5588449 | 27 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 5588451 | 28 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 8 | |
| 2620490 | 29 CLAMP | 2 | |
| 2636342 | 30 CLIP | 10 | |
| 3E3879 | 31 EYEBOLT (M16X2) | 2 | |
| 5D1026 | 32 CLAMP-BAND | 8 | |
| 5P4868 | 33 CLAMP-HOSE | 16 | |
| 6V3378 | 34 CLIP | 8 | |
| 8M2773 | 35 CLIP (LOOP) | 7 | |
| 8T4121 | 36 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4136 | 37 BOLT (M10X1.5X25-MM) | 92 | |
| 8T4137 | 38 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4182 | 39 BOLT (M10X1.5X45-MM) | 8 | |
| 8T4185 | 40 BOLT (M10X1.5X50-MM) | 16 | |
| 8T4191 | 41 BOLT (M10X1.5X16-MM) | 13 | |
| 8T4226 | 42 WASHER-PLATED (10.5X45X3-MM THK) | 16 | |
| 8T4956 | 43 BOLT (M12X1.75X35-MM) | 8 | |
| 5P7211 | 44 SEAL (0.06-M EACH) | ||
| 6V6604 | 45 SEAL (1.62-M EACH) | ||
| 4721116 | 46 HOSE (81-CM) | ||
| 4721116 | 46A HOSE (125-CM) | ||
| 4721116 | 46B HOSE (35-CM) | ||
| 4721116 | 46C HOSE (61-CM) | ||
| 4954683 | 47 HOSE (197-CM) | ||
| 4954683 | 47A HOSE (178-CM) |
