System And Components
541-1950 LINES GP-TURBOCHARGER WATERS/N E291-101
Group No: 541-1950
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3K0360 | 1 SEAL-O-RING | 2 | |
| 7N3368 | 2 GASKET | 1 | |
| 0919035 | 3 SPACER (11X25X20-MM THK) | 1 | |
| 1175208 | 4 CROSS | 1 | |
| 2168580 | 5 SEAL-O-RING | 2 | |
| 3428379 | 6 CONNECTOR | 2 | |
| 3552930 | 7 PLATE | 1 | |
| 3603680 | 8 PLUG (3/4-16-THD)(INTERNAL) | 2 | |
| 5090290 | 9 HOSE AS | 1 | |
| 5090291 | 10 HOSE AS | 1 | |
| 5095656 | 11 HOSE AS | 1 | |
| 5095657 | 12 HOSE AS | 1 | |
| 5095658 | 13 HOSE AS | 1 | |
| 5411949 | 14 BRACKET | 1 | |
| 5411963 | 15 HOSE AS | 1 | |
| 0L1143 | 16 BOLT (3/8-16X2.5-IN) | 1 | |
| 1645615 | 17 ELBOW AS | 1 | |
| 4K1388 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T8986 | ELBOW | 1 | |
| 1808424 | 18 SEAL-O-RING | 5 | |
| 3180820 | 19 GROMMET | 3 | |
| 3B1915 | 20 BOLT (3/8-16X1.375-IN) | 1 | |
| 3E2333 | 21 ELBOW | 1 | |
| 4J5907 | 22 BOLT (3/8-16X1.375-IN) | 3 | |
| 5E9684 | 23 FITTING | 1 | |
| 5K9090 | 24 SEAL-O-RING | 13 | |
| 5P7464 | 25 CLIP (SLOT) | 1 | |
| 5P7465 | 26 CLIP (TAB) | 1 | |
| 6D7128 | 27 SEAL-O-RING | 2 | |
| 6V1581 | 28 CLIP (SLOT) | 1 | |
| 6V1582 | 29 CLIP (TAB) | 1 | |
| 6V3250 | 30 SEAL-O-RING | 1 | |
| 6V5064 | 31 SEAL-O-RING | 2 | |
| 6V7359 | 32 GROMMET (25-MM ID, 37-MM OD) | 1 | |
| 6V8557 | 33 NUT-FACE SEAL (1-7/16-12-THD) | 2 | |
| 6V8781 | 34 TEE (FACE SEAL) | 1 | |
| 6V8944 | 35 REDUCER | 2 | |
| 6V9008 | 36 ELBOW | 1 | |
| 6V9829 | 37 CAP (ORFS) | 1 | |
| 6V9833 | 38 CAP | 1 | |
| 6V9840 | 39 TEE-SWIVEL | 2 | |
| 6V9844 | 40 TEE-SWIVEL | 1 | |
| 7S3916 | 41 CLIP (TAB) | 3 | |
| 7S3919 | 42 CLIP (SLOT) | 3 | |
| 8T6762 | 43 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8T7496 | 44 CONNECTOR | 2 | |
| 8T7526 | 45 SEAL-O-RING | 2 | |
| 9S8752 | 46 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 47 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
