416-4677 COVER GP-VALVE MECHANISMS/N NGH1-UP
Group No: 416-4677
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2274531 | 1 CAP AS-ENGINE OIL FILLER | 1 | |
| 7F8268 | SEAL-O-RING | 1 | |
| 2444500 | 2 SPRING | 10 | |
| 2600113 | 3 SEAL-VALVE COVER | 1 | |
| 3249326 | 4 COVER-VALVE MECHANISM | 1 | |
| 3587347 | 5 BRACKET | 1 | |
| 5826323 | 6 BREATHER AS (VALVE MECHANISM) | 1 | |
| 8T9527 | SEAL-O-RING | 1 | |
| 0619456 | SEAL-O-RING | 1 | |
| 5741230 | CLAMP-V-BAND | ||
| 1310353 | 7 STUD (M8X1.25X82.75-MM) | 2 | |
| 3E4352 | 8 WASHER-HARD (8.8X20.5X2.5-MM THK) | 10 | |
| 5P7970 | 9 NUT (M8X1.25-THD) | 2 | |
| 5P8244 | 10 WASHER-HARD (12X22.5X2.5-MM THK) | 10 | |
| 8T0100 | 11 BOLT (M8X1.25X60-MM) | 8 | |
| 9M1974 | 12 WASHER-HARD (8.8X16X2-MM THK) | 2 |
