System And Components
344-5154 BASE GP-OIL FILTERS/N NGH1-UP
Group No: 344-5154
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C1493 | 1 VALVE AS-BYPASS | 1 | |
| 2423864 | 2 SPRING | 1 | |
| 2097290 | 3 GASKET | 1 | |
| 3595999 | 4 BASE | 1 | |
| 8T0276 | 5 BOLT (M8X1.25X45-MM) | 9 | |
| 3985596 | 6 PLUG AS | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3095137 | 7 CONNECTOR AS | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3779593 | 8 PLUG AS | 1 | |
| 9N6152 | PLUG | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3309754 | 9 CONNECTOR AS | 1 | |
| 8T3611 | CONNECTOR | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 6V2317 | 10 BOLT (M8X1.25X30-MM) | 2 | |
| 9M1974 | 11 WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 9X2098 | 12 STUD-TAPERLOCK (M8X1.25X45-MM) | 1 |
