System And Components
228-0780 COOLER GP-TRANSMISSION OILS/N NGH1-UP
Group No: 228-0780
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S0795 | 1 GASKET | 2 | |
| 6F7062 | 2 WASHER (12.7X19.05X1.83-MM THK) | 1 | |
| 8M9307 | 3 PLUG (TRANSMISSION OIL COOLER) | 1 | |
| 8S4304 | 4 BONNET-XMSN OIL COOLER | 1 | |
| 1275537 | 5 CORE AS (TRANSMISSION OIL) | 1 | |
| 4337092 | 6 BRACKET | 1 | |
| 1803907 | 7 SEAL-INTEGRAL | 1 | |
| 1808420 | 8 BONNET | 1 | |
| 0S1595 | 9 BOLT (1/2-13X1.25-IN) | 4 | |
| 3960403 | 10 PLUG AS | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3985596 | 11 PLUG AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 4337084 | 12 BRACKET | ||
| 6V1819 | 13 BOLT (M10X1.5X100-MM) | 1 | |
| 9X8873 | 14 BOLT (1/2-13X2.25-IN) | 2 | |
| 3893728 | 15 PLUG AS | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3603684 | PLUG | 1 | |
| 7X2543 | 16 BOLT (M10X1.5X120-MM) | 2 | |
| 8T7950 | 17 BOLT (M10X1.5X180-MM) | 3 | |
| 6V8675 | 18 BOLT (M12X1.75X35-MM) | 2 | |
| 6V4248 | 19 BOLT (M10X1.5X25-MM) | 2 | |
| 5P8245 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 3E4353 | 21 WASHER-HARD (11X25X3-MM THK) | 2 | |
| 9X8877 | 22 BOLT (1/2-13X5-IN) | 6 | |
| 1983462 | 23 DIVERTER | 1 |
