System And Components
350-5472 COOLER GP-TRANSMISSION OILS/N NGH1-UP
Group No: 350-5472
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E8570 | 1 BONNET | 1 | |
| 1757453 | 2 CORE AS-TRANSMISSION COOLER | 1 | |
| 1803907 | 3 SEAL-INTEGRAL (TRANSMISSION COOLER) | 1 | |
| 1983462 | 4 DIVERTER | 1 | |
| 3779603 | 5 VALVE AS-FLUID SAMPLING | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 1549023 | VALVE-SAMPLING | 1 | |
| 4449156 | 6 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 1394255 | SPACER (10X20X7-MM THK) | 2 | |
| 3571096 | 7 BONNET-COOLER | 1 | |
| 1292861 | 8 GASKET | 2 | |
| 1570670 | 9 CAP-DUST | 1 | |
| 3985614 | 10 PLUG AS | 1 | |
| 6V5064 | SEAL-O-RING | 1 | |
| 3603684 | PLUG | 1 | |
| 5P8347 | 11 BOLT (M8X1.25X70-MM) | 2 | |
| 6V2317 | 12 BOLT (M8X1.25X30-MM) | 6 | |
| 6V5839 | 13 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V6317 | 14 BOLT (M10X1.5X20-MM) | 2 | |
| 3985598 | 15 PLUG AS | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 8C2926 | 16 BOLT (M10X1.5X140-MM) | 3 | |
| 8T6854 | 17 BOLT (M10X1.5X200-MM) | 1 | |
| 8T9085 | 18 BOLT (M10X1.5X150-MM) | 2 |
