System And Components
275-0815 DRIVE GP-TRANSFER -DISCONNECTS/N GFY300-UP
Group No: 275-0815
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3J1907 | 1 SEAL-O-RING | 2 | |
| 6V0852 | 2 CAP-DUST | 2 | |
| 6V3965 | 3 FITTING (QUICK DISCONNECT) | 2 | |
| 9X7686 | 4 SEAL-O-RING | 1 | |
| 1788210 | 5 SEAL | 1 | |
| 1977334 | 6 SEAL | 1 | |
| 2739146 | 7 SHAFT | 1 | |
| 2743961 | 8 BEARING AS-TAPERED ROLLER | 1 | |
| 2747437 | 9 SEAL-LIP TYPE | 1 | |
| 2750811 | 10 PISTON | 1 | |
| 2750812 | 11 COVER | 1 | |
| 2750817 | 12 HOUSING | 1 | |
| 2750819 | 13 HUB | 1 | |
| 2750820 | 14 ROD | 1 | |
| 2750821 | 15 COLLAR-SLIDING | 1 | |
| 2750822 | 16 CARRIER-BEARING | 1 | |
| 2755737 | 17 RING-RETAINING | 1 | |
| 2803943 | 18 SPACER | 2 | |
| 2830160 | 19 FORK-SHIFT | 1 | |
| 3605697 | 20 ROTOR-SENSOR (OUTPUT SPEED) | 1 | |
| 2940356 | 21 SPRING | 2 | |
| 1364183 | 22 BOLT-12 POINT HEAD (M10X1.5X30-MM) | 5 | |
| 1381645 | 23 PIN-SPRING | 1 | |
| 1488407 | 24 PLUG AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J2506 | 25 SEAL-O-RING | 4 | |
| 4L7711 | 26 SEAL-O-RING | 1 | |
| 6H5829 | 27 RING-RETAINING | 2 | |
| 6V3543 | 28 DOWEL | 2 | |
| 6V5230 | 29 BOLT (M10X1.5X60-MM) | 10 | |
| 6V5839 | 30 WASHER (11X21X2.5-MM THK) | 10 | |
| 8C3979 | 31 RING-RETAINING | 1 | |
| 9J4871 | 32 BALL | 2 |
