System And Components
296-5812 HOUSING GP-TORQUE CONVERTERS/N PFW1-578
Group No: 296-5812
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B6161 | 1 LOCK | 1 | |
| 2P8986 | 2 CUP-BEARING | 1 | |
| 2P8987 | 3 CONE-BEARING | 1 | |
| 4H6112 | 4 BREATHER (SWING DRIVE)(TORQUE CONVERTER) | 1 | |
| 4H7859 | 5 LOCKNUT-BEARING | 1 | |
| 5P8245 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 5P8347 | 7 BOLT (M8X1.25X70-MM) | 2 | |
| 3380891 | 8 PLATE-INFORMATION (TRANSMISSION) | 1 | |
| 6V3551 | 9 SEAL-O-RING | 1 | |
| 6V5839 | 10 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V5843 | 11 BOLT (M10X1.5X45-MM) | 1 | |
| 6V7421 | 12 CONE-SPECIAL TAPERED | 2 | |
| 6V7422 | 13 CUP-SPECIAL TAPERED | 2 | |
| 7L9061 | 14 SEAL-O-RING | 2 | |
| 8H7801 | 15 CONE-BEARING | 1 | |
| 8H7803 | 16 CUP-BEARING | 1 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 11 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1363378 | 19 SEAL-O-RING | 1 | |
| 2655834 | 20 MANIFOLD | 1 | |
| 3660683 | 21 MANIFOLD | 1 | |
| 2655840 | 22 GEAR (70-TEETH) | 1 | |
| 2664181 | 23 HOUSING AS-TORQUE CONVERTER | 1 | |
| 5M7937 | DOWEL | 2 | |
| 2656991 | INSERT-THREADED (M16X2-THD) | 12 | |
| 2664188 | INSERT-THREADED (M8X1.25-THD) | 9 | |
| 3632112 | 24 SEAL-LIP TYPE | 1 | |
| 2744254 | 25 RING-SEAL | 1 | |
| 2746111 | 26 RACE-BEARING | 1 | |
| 2749319 | 27 CARRIER AS-RING | 1 | |
| 1A2223 | DOWEL | 1 | |
| 3802810 | 28 SHIELD AS | 1 | |
| 2958261 | 29 GEAR (55-TEETH) | 1 | |
| 1729966 | 30 BOLT (M12X1.75X65-MM) | 13 | |
| 6V5684 | 31 BOLT (M12X1.75X45-MM) | 7 | |
| 8T4184 | 32 BOLT (M12X1.75X45-MM) | 13 | |
| 2744252 | 33 RING-RETAINING | 1 |
