System And Components
383-2060 HOUSING GP-TORQUE CONVERTERS/N PFW452-UP; GFY300-UP
Group No: 383-2060
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B6161 | 1 LOCK | 1 | |
| 2P8986 | 2 CUP-BEARING | 1 | |
| 2P8987 | 3 CONE-BEARING | 1 | |
| 4H7859 | 4 LOCKNUT-BEARING | 1 | |
| 5P8245 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 5P8347 | 6 BOLT (M8X1.25X70-MM) | 2 | |
| 6V3551 | 7 SEAL-O-RING | 1 | |
| 6V5684 | 8 BOLT (M12X1.75X45-MM) | 6 | |
| 6V5839 | 9 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V5843 | 10 BOLT (M10X1.5X45-MM) | 1 | |
| 4166337 | 11 BEARING | 2 | |
| 4166338 | 12 BEARING-CUP | 2 | |
| 7L9061 | 13 SEAL-O-RING | 2 | |
| 8H7801 | 14 CONE-BEARING | 1 | |
| 8H7803 | 15 CUP-BEARING | 1 | |
| 8T3491 | 16 ELBOW | 1 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 17 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1363378 | 19 SEAL-O-RING | 1 | |
| 2582829 | 21 BREATHER (TORQUE CONVERTER) | 1 | |
| 2655834 | 22 MANIFOLD | 1 | |
| 2655840 | 23 GEAR (70-TEETH) | 1 | |
| 3632112 | 24 SEAL-LIP TYPE | 1 | |
| 2744252 | 25 RING-RETAINING | 1 | |
| 2744254 | 26 RING-SEAL | 1 | |
| 2746111 | 27 RACE-BEARING | 1 | |
| 4190034 | 28 CARRIER AS | 1 | |
| 1A2223 | DOWEL | 1 | |
| 3802810 | 29 SHIELD AS | 1 | |
| 2958261 | 30 GEAR (55-TEETH) | 1 | |
| 3660683 | 31 MANIFOLD | 1 | |
| 3048981 | 32 PLATE-LIFTING | 1 | |
| 5159355 | 33 HOUSING AS-TORQUE CONVERTER | 1 | |
| 1A2223 | DOWEL | 4 | |
| 5M7937 | DOWEL | 2 | |
| 3380891 | 34 PLATE-INFORMATION (TRANSMISSION) | 1 | |
| 0336036 | 35 SEAL-O-RING | 1 | |
| 1729966 | 36 BOLT (M12X1.75X65-MM) | 13 | |
| 3072671 | 37 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2465451 | 38 STUD-TAPERLOCK (M12X1.75X65-MM) | 13 | |
| 6V8197 | 39 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4183 | 40 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4244 | 41 NUT (M12X1.75-THD) | 13 |
