System And Components
422-1817 HOUSING GP-TORQUE CONVERTERS/N PFW579-UP
Group No: 422-1817
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B6161 | 1 LOCK | 1 | |
| 2P8986 | 2 CUP-BEARING | 1 | |
| 2P8987 | 3 CONE-BEARING | 1 | |
| 4H6112 | 4 BREATHER (SWING DRIVE)(TORQUE CONVERTER) | 1 | |
| 4H7859 | 5 LOCKNUT-BEARING | 1 | |
| 5P8245 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 6V3551 | 7 SEAL-O-RING | 1 | |
| 6V5839 | 8 WASHER (11X21X2.5-MM THK) | 1 | |
| 4166337 | 9 BEARING | 2 | |
| 4166338 | 10 BEARING-CUP | 2 | |
| 7L9061 | 11 SEAL-O-RING | 2 | |
| 8H7801 | 12 CONE-BEARING | 1 | |
| 8H7803 | 13 CUP-BEARING | 1 | |
| 9M1974 | 14 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1363378 | 15 SEAL-O-RING | 1 | |
| 2655834 | 16 MANIFOLD | 1 | |
| 2655840 | 17 GEAR (70-TEETH) | 1 | |
| 2744252 | 18 RING-RETAINING | 1 | |
| 2744254 | 19 RING-SEAL | 1 | |
| 2746111 | 20 RACE-BEARING | 1 | |
| 4190034 | 21 CARRIER AS | 1 | |
| 1A2223 | DOWEL | 1 | |
| 3802810 | 22 SHIELD AS | 1 | |
| 2958261 | 23 GEAR (55-TEETH) | 1 | |
| 3380891 | 24 PLATE-INFORMATION (TRANSMISSION) | 1 | |
| 3632112 | 25 SEAL-LIP TYPE | 1 | |
| 3660683 | 26 MANIFOLD | 1 | |
| 3710886 | 27 HOUSING AS-TORQUE CONVERTER | 1 | |
| 5M7937 | DOWEL | 2 | |
| 2656991 | INSERT-THREADED (M16X2-THD) | 10 | |
| 2664188 | INSERT-THREADED (M8X1.25-THD) | 12 | |
| 1729966 | 28 BOLT (M12X1.75X65-MM) | 13 | |
| 5P8347 | 29 BOLT (M8X1.25X70-MM) | 2 | |
| 6V5684 | 30 BOLT (M12X1.75X45-MM) | 7 | |
| 6V5843 | 31 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4184 | 32 BOLT (M12X1.75X45-MM) | 13 | |
| 8T4223 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 13 |
