System And Components
292-0259 WHEEL GP-FINAL DRIVE & BRAKE -REARS/N TJG1-UP
Group No: 292-0259
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1436387 | 1 SEAL-O-RING | 1 | |
| 1508793 | 3 RING-SEAL | 1 | |
| 1700498 | 4 BEARING AS | 1 | |
| 1700497 | 4A CUP-SPECIAL TAPERED | 2 | |
| 2163507 | 4B BEARING-CONE | 2 | |
| 5267064 | CONE-BEARING (CARBON COATING) | 2 | |
| 3718453 | 6 RETAINER-SEAL | 1 | |
| 1863712 | 7 SEAL-O-RING | 1 | |
| 2014606 | 8 BOLT (M36X4X180-MM) | 48 | |
| 3809083 | 9 WHEEL AS | 1 | |
| 1467813 | STUD | 54 | |
| 2179903 | 10 WASHER (39X66X20-MM THK) | 48 | |
| 3824658 | 11 BRAKE GP-SERVICE & PARKING | 1 | |
| 2663610 | 12 HUB | 1 | |
| 2892270 | 13 SEAL-O-RING | 1 | |
| 5433064 | 14 DRIVE GP-FINAL | 1 | |
| 4695270 | 15 HOUSING | 1 | |
| 4430700 | 16 HOUSING | 1 | |
| 3080879 | 17 RETAINER | 1 | |
| 3083083 | 18 ADAPTER AS | 2 | |
| 1467814 | STUD | 25 | |
| 1505134 | STUD | 2 | |
| 5618150 | 19 SPINDLE GP | 1 | |
| 4261742 | 20 GUIDE | 1 | |
| 4287803 | 21 BALL BEARING | 1 | |
| 3116791 | 22 SHIM PACK (INCLUDES 19-SHIMS) | 1 | |
| 3144127 | 24 RING-TORIC | 1 | |
| 5638599 | 25 SEAL GP-DUO-CONE | 1 | |
| 3144129 | RING-TORIC | 2 | |
| 5638601 | 26 SEAL GP-DUO-CONE | 1 | |
| 3144133 | RING-TORIC | 2 | |
| 3406056 | 27 TUBE AS | 2 | |
| 3462140 | 28 PLATE GP-AXLE IDENTIFICATION | 1 | |
| 1052793 | PLATE-SERIAL NUMBER (REAR WHEEL) | 1 | |
| 3298934 | TAPE | 1 | |
| 3529405 | 29 TUBE AS | 2 | |
| 0998111 | 30 PIN-SPRING | 1 | |
| 3E9400 | 31 RING-RETAINING | 1 | |
| 1237274 | 32 SEAL-RING | 1 | |
| 1461799 | 33 WASHER-HARD (39X66X6-MM THK) | 34 | |
| 1488411 | 34 PLUG AS | 3 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1984777 | 35 WASHER-HARD (11X25X10-MM THK) | 12 | |
| 1D0158 | 36 PIN | 1 | |
| 2287091 | 37 SEAL-O-RING | 4 | |
| 2287093 | 38 SEAL-O-RING | 4 | |
| 2416185 | 39 PLUG AS | 3 | |
| 5P9436 | PLUG | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1488410 | 40 PLUG AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 4B9302 | 41 CLIP (LOOP) | 2 | |
| 5P9519 | 42 SEAL-O-RING | 1 | |
| 6V1820 | 43 BOLT (M10X1.5X30-MM) | 2 | |
| 6V3830 | 44 SEAL-O-RING | 2 | |
| 6V5839 | 45 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V8732 | 46 UNION | 2 | |
| 6V8734 | 47 UNION | 2 | |
| 7X4781 | 48 SEAL-O-RING | 1 | |
| 8C3107 | 49 SEAL-O-RING | 2 | |
| 1779755 | 50 BOLT (M30X3.5X160-MM) | 20 | |
| 8C4032 | 51 NUT (M36X4-THD) | 34 | |
| 8T1447 | 52 BOLT-SOCKET HEAD (M16X2X70-MM) | 9 | |
| 8T4186 | 53 BOLT (M10X1.5X40-MM) | 12 | |
| 9X8268 | 54 WASHER (17.5X30X3.5-MM THK) | 9 | |
| 9X8399 | 55 WASHER (33X56X6-MM THK) | 20 | |
| 4907347 | 56 RING-RETAINING | 1 |
