548-8438 PANEL GP-INSTRUMENT -RHAN ATTACHMENT

Group No: 548-8438

Part Number	Part Name	Qty
2N5848	1 BASE AS	1
2W8436	2 INDICATOR AS-PRESSURE	1
9X6259	3 SCREW-MACHINE (6-32X0.375-IN)	2
6J3958	4 COUPLING-PIPE	2
3B7721	5 BUSHING-REDUCER	1
9X6772	6 STRAP-CABLE	6
6L2845	7 BRACKET-MOUNTING	1
2005724	9 ADAPTER	1
0L1352	10 BOLT (3/8-16X3.25-IN)	1
1653929	11 BOLT (3/8-16X1.5-IN)	2
0T0102	12 BOLT (3/8-16X0.625-IN)	2
1W8493	13 GAUGE AS-PRESSURE	1
4B2049	NUT (10-32-THD)	2
6V3507	SEAL-RECTANGULAR	1
7W2731	RETAINER	1
8F1434	LOCKWASHER	2
2B0941	14 SPACER (10.5X19X19-MM THK)	2
2005222	15 GAUGE GP-COOLANT TEMPERATURE	1
4B2049	NUT (10-32-THD)	2
8F1434	LOCKWASHER	2
2B2404	16 CLIP	1
2G4706	17 HOSE AS	1
2H3755	18 BOLT (5/16-18X0.43-IN)	2
2N0816	19 PANEL-INSTRUMENT	1
2N1287	20 ELBOW-FLARED	1
3181181	21 SENSOR GP-SPEED (MAGNETIC)(ENGINE OUTPUT)	1
3B7263	22 NIPPLE-PIPE	1
3J1907	23 SEAL-O-RING	1
3L2875	24 CLIP	3
3S1099	25 ELBOW-FLARED	2
4B2041	26 NUT (6-32-THD)	2
4B4281	27 WASHER (16.8X33X2.5-MM THK)	1
4P7429	28 CLIP (LADDER)	1
4P7581	29 CLIP (LADDER)	3
4P8134	30 CLIP (LADDER)	2
5M2894	31 WASHER-HARD (10.2X18.5X2.5-MM THK)	5
5P0537	32 WASHER-HARD (7.2X14.5X2-MM THK)	6
5S0003	33 NUT (5/16-18-THD)	2
5T4375	34 HOSE AS	1
6V3507	35 SEAL-RECTANGULAR	3
7J4026	36 ELBOW	1
7K9197	37 ELBOW	3
7W2731	38 RETAINER	3
8F0244	39 GROMMET	3
8L6557	40 CONNECTOR	2
8N1702	41 HOSE AS	1
9B1117	42 LOCKWASHER	2
9F6580	43 BOLT (1/4-20X1.125-IN)	3
9M1974	44 WASHER-HARD (8.8X16X2-MM THK)	4
9S8750	45 NUT-FULL (1/4-20-THD)	3
9Y3384	46 COVER-PANEL	1
3664622	KIT-SERVICE METER (32-VOLT DC)	1
