System And Components
246-6707 LINES GP-WATERS/N B541-UP
Group No: 246-6707
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P4961 | 1 CLAMP-HOSE | 4 | |
| 5P1262 | 2 HOSE (16-CM) | ||
| 9X3982 | 3 ELBOW | 1 | |
| 1498142 | 4 CONNECTOR | 1 | |
| 1842420 | 6 ADAPTER AS | 2 | |
| 3E7401 | ADAPTER | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1842509 | 7 VALVE GP-DRAIN (COOLANT) | 2 | |
| 7E4761 | VALVE-DRAIN | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 3520401 | 8 TUBE AS | 1 | |
| 2627688 | 9 TUBE AS | 1 | |
| 2627689 | 10 TUBE AS | 1 | |
| 2627692 | 11 BRACKET AS | 1 | |
| 2659385 | 12 HOSE | 1 | |
| 2667650 | 13 ELBOW | 1 | |
| 2667651 | 14 HOSE | 1 | |
| 2696650 | 15 ADAPTER | 2 | |
| 2924417 | 16 PLATE AS | 1 | |
| 2957612 | 17 BRACKET AS | 1 | |
| 1488367 | 18 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T4984 | 20 CLAMP-HOSE | 8 | |
| 8T6703 | 21 CLAMP-HOSE | 4 | |
| 3K0360 | 22 SEAL-O-RING | 2 | |
| 5P4116 | 24 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 5P7468 | 25 CLIP (SLOT) | 1 | |
| 5P7469 | 26 CLIP (TAB) | 1 | |
| 6V1581 | 27 CLIP (SLOT) | 1 | |
| 6V1582 | 28 CLIP (TAB) | 1 | |
| 6V9168 | 29 NUT (11/16-16-THD) | 2 | |
| 7X7729 | 30 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 34 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 35 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4189 | 36 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4195 | 37 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4196 | 38 BOLT (M10X1.5X35-MM) | 2 | |
| 9D6196 | 39 CLIP (SLOT) | 1 | |
| 9D6197 | 40 CLIP (TAB) | 1 | |
| 6V8523 | 41 HOSE (20-CM) | ||
| 6V8523 | 41A HOSE (60-CM) | ||
| 5P1259 | 42 HOSE (13-CM EACH) |
