Assembly
100%

357-9652 WIPER GP-WINDOW -DOOR, RHS/N B541-UP

Group No: 357-9652
Part NumberPart NameQty
35320171 FITTING1
3S20932 STRAP-CABLE3
5C88113 BLADE AS-WIPER (500-MM)(UPPER)1
6V58514 BLADE AS-WIPER (400-MM)(LOWER)1
7Y34745 VALVE AS-CHECK (WINDOW WASHER)1
8T54006 CONNECTOR2
25694487 ARM GP-WINDOW WIPER (UPPER)1
8T1119NOZZLE AS-WASHER1
2408666CLIP3
1945171HOSE (58-CM)
29511178 ARM GP-WINDOW WIPER (LOWER)1
8T1119NOZZLE AS-WASHER1
2408666CLIP3
1945171HOSE (60-CM)
35796549 LINKAGE GP-WIPER (RH)1
3F9556LOCKWASHER2
5C7261NUT (M8X1.25-THD)2
2065823CAP (WIPER MOTOR)2
511237110 MOTOR GP-WINDOW WIPER (24-VOLT, 2-SPEED)1
3F955611 LOCKWASHER1
344567412 NUT (M8X1.25-THD)1
1H324413 LOCKWASHER3
8T497014 BOLT (M6X1X14-MM)3
144019515 HOSE (11-CM EACH)
144019515A HOSE (18-CM)
