System And Components
305-2889 LINES GP-POWER TRAIN OILS/N EB21-UP
Group No: 305-2889
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2843502 | 1 CLAMP-BAND | 2 | |
| 8T6703 | 2 CLAMP-HOSE | 2 | |
| 9J3866 | 3 ADAPTER | 1 | |
| 3703811 | 4 HOSE AS | 1 | |
| 1911859 | 5 HOSE AS | 1 | |
| 2104458 | 6 ELBOW | 1 | |
| 1226908 | 7 HOSE-HYDRAULIC (19.3-IN) | ||
| 2609143 | 8 ELBOW AS | 1 | |
| 1095824 | ELBOW (SWIVEL) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 2696974 | 9 TUBE AS | 1 | |
| 2801766 | 10 SLEEVE | 1 | |
| 2911965 | 11 HOSE AS | 1 | |
| 2916128 | 12 HOSE AS | 1 | |
| 3283655 | 14 FILTER ELEMENT AS-OIL (ADVANCED EFFICIENCY, WITH SEAL)(NON-METALLIC) | 1 | |
| 3494384 | 15 HOSE AS | 1 | |
| 3494385 | 16 HOSE AS | 1 | |
| 3494386 | 17 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3494387 | 18 BRACKET | 1 | |
| 3494927 | 19 HOSE AS | 1 | |
| 0672551 | 20 CLIP | 1 | |
| 1488323 | 21 CONNECTOR AS | 1 | |
| 6V9875 | CONNECTOR | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1488325 | 22 CONNECTOR AS | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488336 | 23 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488339 | 24 CONNECTOR AS | 2 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488378 | 26 ELBOW AS | 3 | |
| 6V8724 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488392 | 27 ELBOW AS | 1 | |
| 6V9853 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1654854 | 28 SEAL-O-RING | 2 | |
| 1695864 | 29 STEM AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 0694269 | ADAPTER | 1 | |
| 1P4577 | 30 FLANGE-HALF | 4 | |
| 1P4578 | 31 FLANGE-HALF | 2 | |
| 1S9799 | 32 SEAL-O-RING | 1 | |
| 4J0520 | 33 SEAL-O-RING | 4 | |
| 4J0522 | 34 SEAL-O-RING | 1 | |
| 5S7382 | 36 BOLT (3/8-16X1.375-IN) | 8 | |
| 6D3479 | 37 CLIP (LOOP) | 1 | |
| 6V8400 | 38 SEAL-O-RING | 1 | |
| 0673045 | 39 CLIP (LOOP) | 6 | |
| 8C3206 | 40 FLANGE-HALF | 2 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 19 | |
| 3445675 | 42 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 43 BOLT (M10X1.5X25-MM) | 5 | |
| 8T4137 | 44 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4183 | 45 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4195 | 46 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 47 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4896 | 49 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T5005 | 51 BOLT (M10X1.5X70-MM) | 4 | |
| 4231986 | 52 HOSE (21.2-IN) | ||
| 1488352 | 53 ELBOW AS | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 5K9090 | SEAL-O-RING | 1 |
