System And Components
324-2861 LINES GP-AIR -AIR TO AIR AFTERCOOLINGS/N EB31-UP
Group No: 324-2861
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1770581 | 1 HOSE | 1 | |
| 2011260 | 2 HOSE | 1 | |
| 3255465 | 3 HOSE-ELBOW | 1 | |
| 3255868 | 4 HOSE-ELBOW | 1 | |
| 3255871 | 5 TUBE | 1 | |
| 3255872 | 6 TUBE AS | 1 | |
| 3453816 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 9X2647 | 8 CLIP (TAB) | 1 | |
| 9X2646 | 9 CLIP (SLOT) | 1 | |
| 2094578 | 10 CLAMP-T BOLT | 6 | |
| 6V5039 | 11 CLIP (SLOT) | 1 | |
| 6V5040 | 12 CLIP (TAB) | 1 | |
| 7X7729 | 13 WASHER (11X25X3-MM THK) | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4123 | 15 WASHER (22X35X3.5-MM THK) | 2 | |
| 8T4195 | 16 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4196 | 17 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4780 | 18 BOLT (M20X2.5X30-MM) | 2 | |
| 1440367 | 19 CLAMP-HOSE | 2 | |
| 3487556 | 20 ELBOW-AIR | 1 | |
| 1W5455 | 21 CLAMP-V BAND | 1 |
