380-3055 BATTERY & WIRING GPS/N ENH1-UP

Group No: 380-3055

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	11
6G2256	2 CLAMP	2
7K1181	3 STRAP-CABLE	9
7N0718	4 SWITCH GP-DISCONNECT	1
8S2634	5 COVER AS	1
8W8528	6 SLEEVE	1
9G2758	7 LOCKOUT-SWITCH	1
9G9154	8 CLIP	1
1343344	9 STRAP AS	1
2435821	10 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
2467387	BRACKET	1
1712210	11 CIRCUIT BREAKER AS (80-AMPERE)(MAIN)	2
4E5724	WASHER (7X12X1-MM THK)	2
8T0122	NUT-FULL (1/4-28-THD)	2
1H3244	LOCKWASHER	2
2362340	12 CABLE AS-BATTERY (JUMPER)	1
9G0002	COVER AS-TERMINAL (RED)	1
9G0005	COVER AS-TERMINAL (BLACK)	1
8L8413	STRAP-CABLE (WHITE)	1
8C5918	TERMINAL AS-BATTERY (NEGATIVE)	1
8T9756	TERMINAL AS-BATTERY (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
1598049	CABLE (00-GA, RED)(17-CM)
2418368	13 SWITCH GP-MAGNETIC (24-VOLT)(MAIN POWER RELAY)	1
2668944	14 GROMMET	1
2672744	15 HOLDER AS-FUSE	1
2672746	COVER AS	1
2727239	16 BLOCK AS	2
2883687	17 CIRCUIT BREAKER AS (20-AMPERE)(ENGINE CONTROL)	1
6V8378	NUT (10-32-THD)	2
8F1434	LOCKWASHER	2
8T0328	WASHER-HARD (5.5X10X1-MM THK)	2
3089351	18 CABLE AS	1
9G0005	COVER AS-TERMINAL (BLACK)	1
8L8413	STRAP-CABLE (WHITE)	1
8C5918	TERMINAL AS-BATTERY (NEGATIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
9X9825	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
1598050	CABLE (00-GA, BLACK)(123-CM)
2999092	COVER-TERMINAL (BLACK)	1
3095487	19 PLATE AS	1
3070750	STUD-WELD	2
8T3490	NUT-WELD (M10X1.5-THD)	4
1305300	CLIP	1
3147476	20 COVER AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
3147487	21 STRAP	1
3195098	22 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
3195106	23 PLATE	1
3195109	24 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
7T4924	COVER-TERMINAL (RED)	1
1598049	CABLE (00-GA, RED)(70-CM)
2246136	TUBE (7-CM)
3195119	25 COVER	1
3195128	26 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
3195166	27 CABLE AS-AUXILIARY START	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
1598049	CABLE (00-GA, RED)(73-CM)
1598050	CABLE (00-GA, BLACK)(60-CM)
2246136	TUBE (4-CM)
3195167	28 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	2
1598049	CABLE (00-GA, RED)(86-CM)
3288426	COVER-TERMINAL	1
2246136	TUBE (8-CM)
3195192	29 CABLE AS	1
8N1725	COVER AS-TERMINAL (RED)	1
8L8413	STRAP-CABLE (WHITE)	1
3S6049	TERMINAL AS-BATTERY (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
1598049	CABLE (00-GA, RED)(30-CM)
1903848	TERMINAL-RING (00-GA, 1/2-IN SCREW)	1
3223245	30 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	4
3379078	31 SWITCH GP-MAGNETIC (24-VOLT TO 32-VOLT)(SECONDARY STEERING RELAY)	1
3471838	32 CABLE AS	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
1598049	CABLE (00-GA, RED)(61-CM)
2767278	TERMINAL-RING	1
2996082	COVER-TERMINAL (RED)	1
3288425	COVER-TERMINAL (RED)	1
2246136	TUBE (7-CM)
3471842	33 PLATE AS	1
6V9632	NUT-WELD (M6X1-THD)	2
8T3490	NUT-WELD (M10X1.5-THD)	1
8T6466	BOLT (M10X1.5X60-MM)	2
3471843	34 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
8T4195	BOLT (M10X1.5X30-MM)	1
3471844	35 PLATE AS	1
6V9632	NUT-WELD (M6X1-THD)	4
3516621	36 CABLE AS	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
1598050	CABLE (00-GA, BLACK)(28-CM)
2767278	TERMINAL-RING	1
3690930	37 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
5506558	38 HARNESS AS-SWITCH	1
3803056	39 HARNESS AS-POWER	1
1028802	KIT-RECEPTACLE (2-PIN)	1
1028801	KIT-RECEPTACLE (12-PIN)	2
7G7918	PLUG-SEAL	4
7G7920	PLUG-SEAL	1
7R2750	SEAL-CONNECTOR	4
7R2751	PLUG-CONNECTOR (1-PIN)	14
7T0093	PIN-CONNECTOR (12-GA TO 14-GA)	5
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	22
8T8737	PLUG-SEAL	13
9W0852	PIN-CONNECTOR (14-GA TO 16-GA)	5
1138490	FUSE (10-AMPERE)	3
1138491	FUSE (15-AMPERE)	3
1138492	FUSE (20-AMPERE)	2
1243548	FUSE (30-AMPERE)	2
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(15-CM)
1284123	SEAL-CABLE	11
1285016	SEAL-CABLE	12
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	1
5P3454	TERMINAL-RING (4-GA, 5/16-IN SCREW)	1
2L8066	TERMINAL-RING (10-GA TO 12-GA, NO. 10 SCREW)	1
2020313	TERMINAL AS (18-GA)	11
1285016	SEAL-CABLE	1
2020315	TERMINAL AS (12-GA)	1
2020314	TERMINAL AS (14-GA)	14
1284123	SEAL-CABLE	1
2110052	NUT (1-11/16-18-THD)	2
2130143	CONNECTOR (19-PIN)	1
2482841	RELAY AS (24-VOLT)(MAIN)	5
3100674	LOCKWASHER	2
3352318	BLOCK AS-FUSE	1
3060350	COVER	1
3060351	SEAL-COVER	1
3612945	RECEPTACLE AS	1
4254513	RETAINER	1
3803057	40 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
3803068	41 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
0301705	TERMINAL-CABLE (00-GA, 5/16-IN SCREW)	1
1598049	CABLE (00-GA, RED)(116-CM)
3288425	COVER-TERMINAL (RED)	1
2246136	TUBE (7-CM)
3803069	42 CABLE AS	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
1598049	CABLE (00-GA, RED)(84-CM)
3288425	COVER-TERMINAL (RED)	1
2246136	TUBE (4-CM)
0910081	43 SPACER (10.5X20X10-MM THK)	1
2098296	44 BOLT-SOCKET HEAD (M8X1.25X25-MM)	4
1138373	45 SCREW-BUTTON HEAD (10-32X0.75-IN)	4
1305300	46 CLIP	4
1325789	47 CLIP (LADDER)	1
1343355	48 STRAP AS	1
1504086	49 SCREW (M4X0.7X16-MM)	8
1745907	50 CLIP	1
1F7854	51 SPACER (11.01X19.05X49.21-MM THK)	1
1H3244	52 LOCKWASHER	1
2042281	53 STRAP-CABLE	10
2048000	54 MOUNTING-CABLE TIE	10
2233490	55 CLIP	2
2G8767	56 WASHER (10.5X60X3-MM THK)	2
3023908	57 SPACER (11X20X30-MM THK)	1
3445675	58 NUT (M10X1.5-THD)	9
4B4274	59 WASHER (5.5X13X1.2-MM THK)	4
3523968	60 CLIP (LADDER)	1
5416629	61 CLIP (LOOP)	13
5C2890	62 NUT (M6X1-THD)	3
5C7261	63 NUT (M8X1.25-THD)	2
5P4116	64 WASHER-HARD (8.8X20.5X2-MM THK)	5
6V3265	65 CLIP	2
6D4244	66 CLIP (LOOP)	2
6D4636	67 CLIP (LOOP)	1
6G2263	68 SPACER (10.5X19X28.5-MM THK)	2
6W6672	69 SPACER (10.5X20X38-MM THK)	3
7V6571	70 GROMMET	15
7X7729	72 WASHER (11X25X3-MM THK)	5
8D7712	73 FASTENER	4
8T0328	74 WASHER-HARD (5.5X10X1-MM THK)	4
8T4121	75 WASHER-HARD (11X21X2.5-MM THK)	59
8T4136	77 BOLT (M10X1.5X25-MM)	32
8T4137	78 BOLT (M10X1.5X20-MM)	10
8T4138	79 BOLT (M6X1X20-MM)	6
8T4179	80 BOLT (M12X1.75X20-MM)	1
8T4186	81 BOLT (M10X1.5X40-MM)	1
8T4191	82 BOLT (M10X1.5X16-MM)	2
8T4192	83 BOLT (M12X1.75X25-MM)	2
8T4196	84 BOLT (M10X1.5X35-MM)	3
8T4205	85 WASHER-HARD (7.2X14.5X2-MM THK)	1
8T4223	86 WASHER-HARD (13.5X25.5X3-MM THK)	3
8T5005	87 BOLT (M10X1.5X70-MM)	3
8T6466	88 BOLT (M10X1.5X60-MM)	2
8T7547	89 BOLT (M8X1.25X30-MM)	1
9B7233	90 LOCKWASHER	2
4904245	91 WASHER-CONICAL	2
9X6016	92 SCREW-HEX SOCKET (8-32X0.875-IN)	2
9X8256	93 WASHER (6.6X12X2-MM THK)	8
7X7877	94 STRIP-EDGE (22-CM)
9X2092	95 TRIM-EDGE (38-CM)
4B4277	96 WASHER (8.8X17.5X1.6-MM THK)	4
3553148	97 SWITCH AS-PRESSURE (HIGH, LOW)	1
1496371	98 SWITCH AS-PRESSURE (A/C COMPRESSOR CLUTCH)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
