System And Components
571-3645 LINES GP-OIL -SERVICE, LH
Group No: 571-3645
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1588 | 1 BOLT (3/8-16X1.25-IN) | 6 | |
| 1653929 | 2 BOLT (3/8-16X1.5-IN) | 5 | |
| 0S1594 | 3 BOLT (3/8-16X1-IN) | 2 | |
| 2147568 | 4 SEAL-O-RING | 2 | |
| 2P1314 | 5 CONNECTOR | 1 | |
| 3410058 | 6 TUBE AS | 1 | |
| 1135304 | 7 SEAL-O-RING | 2 | |
| 3V3308 | 8 WASHER-HARD (10.2X20.5X2.5-MM THK) | 14 | |
| 4309452 | 9 SENSOR GP-LIQUID LEVEL (HYDROCARBON) | 1 | |
| 4W6638 | 10 GASKET | 1 | |
| 6V5055 | 11 SEAL-O-RING | 1 | |
| 7E5038 | 12 VALVE (PILOT OPERATED) | 1 | |
| 7E5041 | 13 ELBOW | 1 | |
| 7E5049 | 14 TUBE AS | 1 | |
| 7E5068 | 15 CLAMP AS | 4 | |
| 7E5460 | 16 RING-RETAINING | 2 | |
| 7E8320 | 17 BRACKET AS | 1 | |
| 7J4026 | 18 ELBOW | 1 | |
| 8M9024 | 19 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9D6196 | 20 CLIP (SLOT) | 1 | |
| 9D6197 | 21 CLIP (TAB) | 1 | |
| 9L9132 | 22 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 5 | |
| 1695428 | KIT-SEAL REPAIR | 1 |
