System And Components
463-3515 LINES GP-PRELUBRICATIONSERVICE, LH
Group No: 463-3515
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S8752 | 1 NUT-FULL (3/8-16-THD) | 5 | |
| 4W6638 | 2 GASKET | 1 | |
| 6V5055 | 3 SEAL-O-RING | 1 | |
| 1695428 | 4 KIT-SEAL REPAIR | 1 | |
| 7E5041 | 5 ELBOW | 1 | |
| 7E5049 | 6 TUBE AS | 1 | |
| 7E5068 | 7 CLAMP AS | 4 | |
| 7E5460 | 8 RING-RETAINING | 2 | |
| 7E8320 | 9 BRACKET AS | 1 | |
| 3410058 | 12 TUBE AS | 1 | |
| 4309452 | 13 SENSOR GP-LIQUID LEVEL (HYDROCARBON) | 1 | |
| 0S1588 | 15 BOLT (3/8-16X1.25-IN) | 6 | |
| 1653929 | 16 BOLT (3/8-16X1.5-IN) | 5 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 2 | |
| 2147568 | 18 SEAL-O-RING | 2 | |
| 2P1314 | 19 CONNECTOR | 1 | |
| 1135304 | 20 SEAL-O-RING | 2 | |
| 3V3308 | 21 WASHER-HARD (10.2X20.5X2.5-MM THK) | 14 | |
| 7J4026 | 23 ELBOW | 1 | |
| 8M9024 | 24 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9D6196 | 25 CLIP (SLOT) | 1 | |
| 9D6197 | 26 CLIP (TAB) | 1 | |
| 9L9132 | 27 WASHER-HARD (10.2X25.5X2.5-MM THK) | 4 |
