System And Components
586-1326 LINES GP-PILOTPART OF 586-1328 HYDRAULIC AR
Group No: 586-1326
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0961366 | 1 CLAMP-HOSE | 1 | |
| 0966079 | 2 TAPE (WHITE) | 2 | |
| 1488307 | 3 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P8874 | ADAPTER | 1 | |
| 1488318 | 4 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 1488443 | 5 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 7X2459 | ADAPTER-TEE | 1 | |
| 1639772 | 6 HOSE AS | 1 | |
| 2057198 | 7 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 0869035 | TEE | 1 | |
| 2458595 | 8 SHEET-RUBBER | 1 | |
| 2674042 | 9 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2674041 | CONNECTOR | 1 | |
| 2674046 | 10 ELBOW AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2674045 | ELBOW | 1 | |
| 2674048 | 11 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2674047 | ELBOW | 1 | |
| 2674093 | 12 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2163247 | CONNECTOR | 1 | |
| 2880266 | 13 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2880267 | ELBOW | 1 | |
| 3597225 | 14 VALVE GP-SOLENOID (AUXILIARY) | 1 | |
| 3779033 | 15 BLOCK GP-HYDRAULIC (BLADE) | 1 | |
| 2P1279 | LOCKNUT (9/16-18-THD) | 2 | |
| 6V9168 | NUT (11/16-16-THD) | 2 | |
| 2939743 | MANIFOLD | 2 | |
| 3779034 | BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3810556 | 16 HOSE AS | 1 | |
| 3810557 | 17 HOSE AS | 1 | |
| 3819194 | 18 HOSE AS | 1 | |
| 3938686 | 19 HOSE AS | 2 | |
| 4709645 | 20 FILTER AS (HYDRAULIC, PILOT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5168706 | 21 ADAPTER-ELBOW | 1 | |
| 1488310 | 22 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8T0151 | ADAPTER | 1 | |
| 1488313 | 23 ADAPTER AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 1488316 | 24 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488325 | 26 CONNECTOR AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1488336 | 27 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488351 | 28 ELBOW AS | 3 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V9849 | ELBOW | 1 | |
| 1488368 | 29 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 1488369 | 30 ELBOW AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8628 | ELBOW | 1 | |
| 1488371 | 31 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 1488407 | 32 PLUG AS | 7 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1503033 | 33 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T0164 | ELBOW | 1 | |
| 1503036 | 34 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 1504047 | 35 ADAPTER AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 8T2353 | ADAPTER | 1 | |
| 1645567 | 36 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1657014 | 37 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C3309 | TEE | 1 | |
| 1872120 | 38 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C8408 | ELBOW | 1 | |
| 2402590 | 39 HOSE AS | 1 | |
| 2553727 | 40 HOSE AS | 2 | |
| 3938366 | 41 HOSE AS | 1 | |
| 4431578 | 42 HOSE AS | 1 | |
| 4593391 | 43 HOSE AS | 1 | |
| 4593392 | 44 HOSE AS | 1 | |
| 4J5477 | 45 SEAL-O-RING | 8 | |
| 5772161 | 46 TEE AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 5772160 | TEE | 1 | |
| 5867800 | 47 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 6V0852 | 48 CAP-DUST | 1 | |
| 6V8397 | 49 SEAL-O-RING | 2 | |
| 7K1181 | 50 STRAP-CABLE | 8 | |
| 7X7729 | 51 WASHER (11X25X3-MM THK) | 2 | |
| 8T3647 | 52 BOLT (M8X1.25X80-MM) | 2 | |
| 8T4121 | 53 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 54 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4224 | 55 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1495933 | 56 SEAL (12-CM) |
