System And Components
Assembly
100%

345-2600 SUPPORT GP-ENGINES/N AX71-UP

Group No: 345-2600
Part NumberPart NameQty
2N50061 BOLT-12 POINT HEAD (1-14X2.5-IN)6
5P80862 BOLT-12 POINT HEAD (1-14X6.5-IN)6
6I45963 PLATE2
7W06594 PLATE-MOUNTING2
7W24255 MOUNT AS2
7W34956 SLEEVE2
7W34987 MOUNT AS2
7W3497MOUNT AS2
8W05878 CAP2
42435059 SUPPORT AS1
1S099410 CLIP (LOOP)1
8T413111 NUT (M20X2.5-THD)4
7X256412 BOLT (M20X2.5X90-MM)4
3E744213 BOLT (M30X3.5X300-MM)2
7X053314 WASHER-HARD (34X55X6-MM THK)2
5M306215 BOLT (3/8-16X0.75-IN)1
5P824716 WASHER-HARD (17X32X3.5-MM THK)16
8T412317 WASHER (22X35X3.5-MM THK)8
5P825018 WASHER (28X49X5-MM THK)6
5P883919 WASHER-HARD (28X42X4-MM THK)6
8K430320 WASHER (33.5X88.9X12-MM THK)2
8C872221 NUT (M30X3.5-THD)2
8T175722 NUT (M16X2-THD)8
8T489623 WASHER-HARD (10.2X18.5X2.5-MM THK)1
8T701324 BOLT (M16X2X220-MM)8
