System And Components
2W-9744 RADIATOR GPWITH DUCT FLANGE
Group No: 2W-9744
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1595 | 1 BOLT (1/2-13X1.25-IN) | 2 | |
| 9M7959 | 2 CLAMP-HOSE | 6 | |
| 3N6036 | 3 HOSE (UPPER RADIATOR) | 1 | |
| 0T0102 | 4 BOLT (3/8-16X0.625-IN) | 2 | |
| 9M5733 | 5 RIVET-POP | 16 | |
| 2L4238 | 6 MOUNT-FLEXIBLE | 4 | |
| 2A4639 | 7 BOLT (3/8-16X1.625-IN) | 4 | |
| 0L1143 | 8 BOLT (3/8-16X2.5-IN) | 6 | |
| 1V7753 | SPACER (0.546X0.841X1.75-IN THK) | 6 | |
| 5P1075 | WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 8L4492 | 9 SHELL AS-RADIATOR | 1 | |
| 9F2978 | 10 NUT-WELD (3/8-16-THD) | 6 | |
| 3N7207 | 11 FLANGE AS-DUCT | 1 | |
| 0S0509 | 12 BOLT (3/8-16X0.75-IN) | 8 | |
| 0L1351 | 13 BOLT (3/8-16X0.875-IN) | 8 | |
| 5P1262 | 14 HOSE (7.62CM) | ||
| 1B5174 | 15 PLUG-PIPE | 1 | |
| 4L2922 | 16 SUPPORT AS | 1 | |
| 4L2921 | 17 SUPPORT AS | 1 | |
| 4B4043 | 18 BOLT (5/8-11X1.375-IN) | 4 | |
| 4L7893 | SHIM (0.598-IN THK) | 4 | |
| 2W3889 | 19 GUARD AS-FAN (UPPER) | 1 | |
| 2W3891 | GUARD AS-FAN (LOWER) | 1 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 3N2669 | 21 ELBOW | 1 | |
| 3N6033 | 22 HOSE-PUMP INLET (LOWER RADIATOR) | 1 | |
| 3F1417 | 23 WASHER (10.3X30.2X3-MM THK) | 8 | |
| 4L2115 | 24 RADIATOR GP | 1 | |
| 6L8617 | 25 CAP-PRESSURE (7-PSI)(PRESSURE) | 1 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 6N7870 | 27 BRACE | 1 | |
| 3L1585 | 28 GASKET | 1 | |
| 4F8965 | 29 BOLT (7/16-14X1.125-IN) | 2 | |
| 4L2138 | 30 ELBOW-RADIATOR OUTLET | 1 | |
| 8N3272 | 31 PLATE-LIFTING EYE | 1 | |
| 4B3823 | 32 BOLT (1/2-13X1.25-IN) | 4 | |
| 0S1594 | 33 BOLT (3/8-16X1-IN) | 2 |
