System And Components
3N-6694 RADIATOR GPHIGH CAPACITY - WITH DUCT FLANGE
Group No: 3N-6694
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1595 | 1 BOLT (1/2-13X1.25-IN) | 2 | |
| 9M7959 | 2 CLAMP-HOSE | 6 | |
| 3N6036 | 3 HOSE (UPPER RADIATOR) | 1 | |
| 0T0102 | 4 BOLT (3/8-16X0.625-IN) | 2 | |
| 9M5733 | 5 RIVET-POP | 24 | |
| 2L4238 | 6 MOUNT-FLEXIBLE | 6 | |
| 2A4639 | 7 BOLT (3/8-16X1.625-IN) | 6 | |
| 0L1143 | 8 BOLT (3/8-16X2.5-IN) | 6 | |
| 1V7753 | SPACER (0.546X0.841X1.75-IN THK) | 6 | |
| 4B4278 | WASHER (10.2X20.5X1.6-MM THK) | 6 | |
| 3N6244 | 9 FLANGE AS-DUCT | 1 | |
| 8L4495 | 10 SHELL AS-RADIATOR | 1 | |
| 9F2978 | 11 NUT-WELD (3/8-16-THD) | 6 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 0L1351 | 13 BOLT (3/8-16X0.875-IN) | 8 | |
| 5P1262 | 14 HOSE (15.24CM) | ||
| 3H3338 | 15 TUBE | 1 | |
| 1B5174 | 16 PLUG-PIPE | 1 | |
| 4L2922 | 17 SUPPORT AS | 1 | |
| 4L2921 | 18 SUPPORT AS | 1 | |
| 4B4043 | 19 BOLT (5/8-11X1.375-IN) | 4 | |
| 4L7893 | SHIM (0.598-IN THK) | 4 | |
| 8N1633 | 20 GUARD AS-FAN (LOWER) | 1 | |
| 2W5643 | GUARD AS-FAN | 1 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 3N2669 | 22 ELBOW | 1 | |
| 3N6033 | 23 HOSE-PUMP INLET (LOWER RADIATOR) | 1 | |
| 0S0509 | 24 BOLT (3/8-16X0.75-IN) | 8 | |
| 3F1417 | WASHER (10.3X30.2X3-MM THK) | 8 | |
| 2N0256 | 25 RADIATOR GP | 1 | |
| 6L8617 | 26 CAP-PRESSURE (7-PSI)(PRESSURE) | 1 | |
| 3J5390 | 27 PLUG (3/8-18-THD) | 1 | |
| 4B3823 | 28 BOLT (1/2-13X1.25-IN) | 4 | |
| 8N3272 | 29 PLATE-LIFTING EYE | 1 | |
| 0S1594 | 30 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 6N7870 | 31 BRACE | 1 |
