System And Components
2W-1736 PUMP GP-GOV & FUEL INJS/N 13E300-600
Group No: 2W-1736
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1066 | 1 LEVER AS-PIVOT | 1 | |
| 7N5334 | 2 SETSCREW-SOCKET (25.4-MM LG) | 1 | |
| 6V6835 | SETSCREW-SOCKET (10-32X0.625-IN)(15.88MM) | 1 | |
| 4B2049 | 3 NUT (10-32-THD) | 1 | |
| 8N4109 | 4 LEVER AS | 1 | |
| 6V6835 | 5 SETSCREW-SOCKET (10-32X0.625-IN) | 1 | |
| 4B2049 | NUT (10-32-THD) | 1 | |
| 4J7533 | 6 SEAL-O-RING | 1 | |
| 2W0263 | 7 PUMP GP-FUEL INJECTION | 1 | |
| 6N1716 | 8 VALVE AS (ADJ FLOW, FUEL PRESSURE RELIEF) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 7N2176 | 9 PIN-DETENT | 1 | |
| 7N1052 | DOWEL | 1 | |
| 8N3093 | 10 SPRING-DETENT | 1 | |
| 0S1616 | 11 BOLT (1/4-20X1-IN) | 3 | |
| 6B4198 | 12 BOLT (1/4-20X4.19-IN) | 2 | |
| 8N3799 | 13 COVER-FUEL RATIO | 1 | |
| 8B2377 | 14 BOLT (1/4-20X2-IN) | 2 | |
| 7N9521 | 15 COVER-FUEL GALLERY | 1 | |
| 9S4180 | 16 PLUG | 1 | |
| 1B2713 | 17 BOLT (1/4-20X1.75-IN) | 2 | |
| 4B4276 | 18 WASHER (7X16X1.6-MM THK) | 2 | |
| 4F7957 | 19 BOLT (1/4-20X0.875-IN) | 4 | |
| 2D6392 | 20 SEAL-O-RING | 1 | |
| 2W2410 | 21 GOVERNOR GP | 1 | |
| 7N8768 | 22 GASKET | 1 | |
| 9S4191 | 23 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | 24 SEAL-O-RING | 1 | |
| 7N3104 | 25 GASKET | 1 | |
| 8L9790 | 26 SPRING | 1 | |
| 4N8507 | 27 COVER | 1 | |
| 4N0117 | GASKET-SOLENOID | 1 | |
| 8N5783 | 28 DEFLECTOR-PULSE | 1 | |
| 0S1614 | 29 BOLT (1/4-20X0.5-IN) | 4 | |
| 8N5403 | 30 SHAFT AS-THROTTLE | 1 | |
| 6M5062 | 31 SEAL-O-RING | 1 | |
| 8N7275 | 32 TORQUE CONTROL GP | 1 | |
| 2S7383 | 33 BOLT (1/4-20X3.25-IN) | 1 | |
| 8F8178 | 34 BOLT (1/4-20X3.25-IN) | 2 | |
| 4N1761 | 35 BOLT (1/4-20X6.5-IN) | 4 | |
| 5D6543 | 36 SEAL-O-RING | 1 | |
| 5L4758 | 37 SEAL-O-RING | 1 |
