System And Components
2W-8364 DRIVE GP-AUXILIARY -REARType 1
Group No: 2W-8364
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W8302 | 1 HOUSING AS-GEAR | 1 | |
| 3F6795 | DOWEL | 6 | |
| 7N3011 | BUSHING | 3 | |
| 7N3007 | 2 SHAFT AS | 3 | |
| 8T2153 | SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 1078748 | 3 GEAR-AUXILIARY DRIVE (75-TEETH) | 2 | |
| 1078749 | 4 GEAR-AUXILIARY DRIVE (83-TEETH) | 1 | |
| 2D8154 | 5 STUD-TAPERLOCK (1/2-13X2.36-IN) | 12 | |
| 1F7958 | 6 NUT-FULL (1/2-13-THD) | 12 | |
| 8T6757 | 7 PLUG-PIPE | 3 | |
| 7X7731 | 8 PLUG-PIPE (3/4-14-THD) | 2 | |
| 7N8525 | 9 WASHER-THRUST | 6 | |
| 8N2757 | 10 ADAPTER AS | 3 | |
| 7N3011 | BUSHING | 1 | |
| 3F5792 | 11 SEAL-O-RING | 3 | |
| 8M5253 | 12 SEAL-O-RING | 3 | |
| 8N2802 | 13 COVER | 1 | |
| 9Y8386 | 14 GASKET | 1 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 0S1588 | 16 BOLT (3/8-16X1.25-IN) | 36 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 36 | |
| 0L1026 | 18 PLUG-CUP | 3 | |
| 1W4736 | 19 GASKET-COVER | 1 | |
| 1T0765 | 20 BOLT (3/8-16X1-IN) | 20 |
