System And Components
8N-9756 DRIVE GP-AUXILIARY -REARREPLACED BY 2W-8364
Group No: 8N-9756
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B5174 | 1 PLUG-PIPE | 2 | |
| 7N3069 | 2 HOUSING AS | 1 | |
| 3F6795 | 3 DOWEL | 6 | |
| 7N3011 | 4 BUSHING | 3 | |
| 7N2990 | 5 GEAR (83 TEETH) | 2 | |
| 2D8154 | 6 STUD-TAPERLOCK (1/2-13X2.36-IN) | 12 | |
| 1D4719 | NUT-FULL (1/2-13-THD) | 12 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8N2757 | 7 ADAPTER AS | 3 | |
| 7N3011 | 8 BUSHING | 1 | |
| 3F5792 | 9 SEAL-O-RING | 3 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN) | 36 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 36 | |
| 9F2247 | 11 PLUG-PIPE (1/8-27-THD) | 3 | |
| 7N8525 | 12 WASHER-THRUST | 6 | |
| 7N2991 | 13 GEAR-AUXILIARY DRIVE (83-TEETH) | 1 | |
| 0L1026 | 14 PLUG-CUP | 3 | |
| 8M5253 | 15 SEAL-O-RING | 3 | |
| 8N2802 | 16 COVER | 3 | |
| 1P9270 | GASKET | 3 | |
| 7N3007 | 17 SHAFT AS | 3 | |
| 8T2153 | 18 SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 1W4736 | 19 GASKET-COVER | 1 |
