Assembly
100%

7C-0299 COVER GP-CYLINDER BLOCKS/N 4KG1-1331; 4KG1540-UP

Group No: 7C-0299
Part NumberPart NameQty
6V23171 BOLT (M8X1.25X30-MM)18
9M19742 WASHER-HARD (8.8X16X2-MM THK)21
7W38723 SLEEVE (MARKED X)6
34249774 COVER-SIDE2
4Y96525 GASKET3
7W93956 COVER-SIDE1
6V52177 BOLT (M8X1.25X20-MM)3
2W65448 COVER1
9S41919 PLUG (9/16-18-THD)3
3J190710 SEAL-O-RING3
4F965311 SEAL-O-RING1
9Y074712 MANIFOLD-OIL1
6V584213 BOLT (M10X1.5X40-MM)2
6V583914 WASHER (11X21X2.5-MM THK)2
110761815 BOLT AS4
517055316 GASKET1
9X209917 STUD (M8X1.25X52.75-MM)2
8T422418 WASHER-HARD (8.8X16X2-MM THK)2
039228120 SPACER (9X16X25-MM THK)1
