System And Components
9Y-6690 COVER GP-CYLINDER BLOCKS/N 7SF18558-19179
Group No: 9Y-6690
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P5153 | 1 MANIFOLD-OIL | 1 | |
| 4Y9652 | 2 GASKET | 3 | |
| 7W3872 | 3 SLEEVE | 6 | |
| 7W9395 | 4 COVER-SIDE | 1 | |
| 1107618 | 5 BOLT AS | 4 | |
| 1U8846 | 6 SEALANT-GASKET | ||
| 3424977 | 7 COVER-SIDE | 2 | |
| 2W6544 | 8 COVER | 1 | |
| 3J7354 | 9 SEAL-O-RING | 1 | |
| 4F9029 | 10 SEAL | 1 | |
| 4F9653 | 11 SEAL-O-RING | 1 | |
| 4W8339 | 12 COVER | 1 | |
| 6V2317 | 13 BOLT (M8X1.25X30-MM) | 19 | |
| 6V5217 | 14 BOLT (M8X1.25X20-MM) | 4 | |
| 7X0818 | 15 BOLT (M8X1.25X45-MM) | 2 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6765 | 19 PLUG-PIPE (1/4-18-THD) | 3 | |
| 9M1974 | 20 WASHER-HARD (8.8X16X2-MM THK) | 23 | |
| 9S4182 | 21 PLUG (7/16-20-THD) | 1 |
