System And Components
135-5991 WIRING GP-ELECTRONIC CONTROLS/N 7AS1-495; 7AS564-13352
Group No: 135-5991
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1538920 | 1 HARNESS AS-ENGINE (UNIT INJECTOR) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 4P5918 | 2 CLIP | 2 | |
| 3S2093 | 3 STRAP-CABLE | 15 | |
| 4P7581 | 4 CLIP (LADDER) | 1 | |
| 5C2890 | 5 NUT (M6X1-THD) | 2 | |
| 0039835 | 6 PROTECTOR | 1 | |
| 1752301 | 8 SWITCH AS-MAGNETIC (12-VOLT)(INLET AIR HEATER RELAY) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 1126646 | LOCKNUT (M6X1-THD) | 2 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 9X1813 | SLEEVE (16CM) | ||
| 7E5714 | 9 STRAP-GROUNDING | 1 | |
| 8T7547 | 10 BOLT (M8X1.25X30-MM) | 1 | |
| 8T4224 | 11 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 1051797 | 12 MOUNT | 7 | |
| 1470286 | 13 WIRE AS | 1 | |
| 2051251 | 14 HARNESS AS (ELECTRONIC CONTROL) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1003320 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 1265011 | SEAL-CONNECTOR | 11 | |
| 1112416 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 1265011 | SEAL-CONNECTOR | 1 | |
| 1607690 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 1599322 | SEAL-O-RING | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 3 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 8T4970 | 15 BOLT (M6X1X14-MM) | 2 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 2 | |
| 1H3338 | 17 LOCKWASHER (EXTERNAL TOOTH) | 2 | |
| 0120380 | 18 LOCKWASHER (6.5X12.5X1.6-MM THK) | 2 |
