Assembly
100%

145-7040 WIRING GP-ELECTRONIC CONTROLS/N 7AS13353-86772

Group No: 145-7040
Part NumberPart NameQty
20512531 HARNESS AS (ELECTRONIC CONTROL)1
3S2093STRAP-CABLE2
8T8737PLUG-SEAL42
1006674SEAL-CONNECTOR2
1111567SOCKET-TERMINAL4
1166158PLUG AS-CONNECTOR (2-PIN)1
1166159SOCKET-TERMINAL2
1166161CAP-CONNECTOR1
1231198SOCKET-TERMINAL2
1231199SEAL-CONNECTOR1
1231200SEAL-CABLE (CABLE)1
1257874TUBE-HEAT SHRINK (5.72-MM DIA)(20-CM)
1257875TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM)
1407339PLUG-CONNECTOR1
9X3401PIN-CONNECTOR (16-GA TO 18-GA)15
1261767PIN-CONNECTOR (14-GA TO 16-GA)15
1945226WIRE AS (16-GA)45
1945227WIRE AS (14-GA)45
1028803KIT-RECEPTACLE (3-PIN)1
1028801KIT-RECEPTACLE (12-PIN)1
1003320PLUG AS-CONNECTOR (2-PIN)1
1265011SEAL-CONNECTOR1
1112416PLUG AS-CONNECTOR (2-PIN)1
1265011SEAL-CONNECTOR1
1607690PLUG AS-CONNECTOR (70-PIN)1
1599322SEAL-O-RING1
1552270KIT-CONNECTING PLUG (2-PIN)4
1552260KIT-CONNECTING PLUG (3-PIN)3
1261774COVER-CONNECTOR1
4P59182 CLIP1
3S20933 STRAP-CABLE19
14702864 WIRE AS1
29055625 MOUNT (DUAL SWIVEL)1
28705696 CLIP1
4P75817 CLIP (LADDER)1
17523248 SWITCH GP-MAGNETIC (24-VOLT)(INLET AIR HEATER)1
7E57149 STRAP-GROUNDING1
8T422410 WASHER-HARD (8.8X16X2-MM THK)1
8T754711 BOLT (M8X1.25X30-MM)1
105179712 MOUNT6
153892013 HARNESS AS-ENGINE (UNIT INJECTOR)1
6N7523WASHER (6.48X11.9X1.57-MM THK)1
9X3402SOCKET-CONNECTOR (16-GA TO 18-GA)12
1261768SOCKET-CONNECTOR (14-GA TO 16-GA)12
1355975GROMMET-WIRING1
1552255KIT-CONNECTING PLUG (12-PIN)1
6V821414 BOLT (M6X1X20-MM)2
9X825615 WASHER (6.6X12X2-MM THK)2
003983516 PROTECTOR2
132578917 CLIP (LADDER)1
