442-7495 WIRING GP-ELECTRONIC CONTROLS/N BDN1-UP

Group No: 442-7495

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	27
7K1181	2 STRAP-CABLE	14
2061346	4 STRAP-CABLE	3
2574907	5 COVER AS-ACCESS	1
7S9930	RING-RETAINING	1
2905562	6 MOUNT (DUAL SWIVEL)	2
3169351	7 MOUNTING-CABLE TIE	6
3438408	8 HARNESS AS-SENSOR (COOLANT TEMPERATURE)	1
3625229	9 BRACKET	1
5707274	10 HARNESS AS-ENGINE	1
0L1351	11 BOLT (3/8-16X0.875-IN)	2
0S0509	12 BOLT (3/8-16X0.75-IN)	6
0S1594	13 BOLT (3/8-16X1-IN)	1
0S1617	14 BOLT (5/16-18X0.75-IN)	1
0S2353	15 BOLT (5/8-18X3.75-IN)	1
4F4879	16 BOLT (3/8-16X0.5-IN)	1
1293172	17 STUD-MOUNTING (3/8-16X1.564-IN)	1
1325789	18 CLIP (LADDER)	7
2663314	19 BOLT-FLANGE HEAD (M6X1X20.5-MM)	1
2771873	20 CLIP (LADDER)	1
2856395	21 CLIP (LADDER)	2
3094314	22 CLIP (LADDER)	1
3523964	23 CLIP (LADDER)	1
3E4352	24 WASHER-HARD (8.8X20.5X2.5-MM THK)	1
4P7581	25 CLIP (LADDER)	2
4P8134	26 CLIP (LADDER)	1
5M2894	27 WASHER-HARD (10.2X18.5X2.5-MM THK)	12
5M3062	28 BOLT (3/8-16X0.75-IN)	1
5P4115	29 WASHER-HARD (7.2X19X2-MM THK)	1
5P4116	30 WASHER-HARD (8.8X20.5X2-MM THK)	4
5P8247	31 WASHER-HARD (17X32X3.5-MM THK)	1
5S0003	32 NUT (5/16-18-THD)	2
6V3940	33 BOLT (M8X1.25X25-MM)	1
6V5215	34 BOLT (M8X1.25X16-MM)	1
6V8801	35 NUT (3/8-16-THD)	1
8T4189	36 BOLT (M8X1.25X20-MM)	4
8T4224	37 WASHER-HARD (8.8X16X2-MM THK)	1
8T4896	38 WASHER-HARD (10.2X18.5X2.5-MM THK)	2
9M1974	39 WASHER-HARD (8.8X16X2-MM THK)	3
9S8752	40 NUT-FULL (3/8-16-THD)	1
