System And Components
341-1973 HOUSING GP-TORQUE CONVERTERS/N PFW556-UP
Group No: 341-1973
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B6161 | 1 LOCK | 1 | |
| 2P8986 | 2 CUP-BEARING | 1 | |
| 2P8987 | 3 CONE-BEARING | 1 | |
| 4H7859 | 4 LOCKNUT-BEARING | 1 | |
| 5P8245 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 5P8347 | 6 BOLT (M8X1.25X70-MM) | 2 | |
| 6V3551 | 7 SEAL-O-RING | 1 | |
| 6V5684 | 8 BOLT (M12X1.75X45-MM) | 6 | |
| 6V5839 | 9 WASHER (11X21X2.5-MM THK) | 14 | |
| 6V5843 | 10 BOLT (M10X1.5X45-MM) | 1 | |
| 6V7421 | 11 CONE-SPECIAL TAPERED | 2 | |
| 6V7422 | 12 CUP-SPECIAL TAPERED | 2 | |
| 7L9061 | 13 SEAL-O-RING | 2 | |
| 8H7801 | 14 CONE-BEARING | 1 | |
| 8H7803 | 15 CUP-BEARING | 1 | |
| 3410107 | 16 ELBOW | 1 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 17 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1281663 | 19 RING-SEAL | 2 | |
| 1363378 | 20 SEAL-O-RING | 1 | |
| 2578660 | 21 BEARING-THRUST | 1 | |
| 2582829 | 22 BREATHER (TORQUE CONVERTER) | 1 | |
| 2655834 | 23 MANIFOLD | 1 | |
| 2655840 | 24 GEAR (70-TEETH) | 1 | |
| 3632112 | 25 SEAL-LIP TYPE | 1 | |
| 2744252 | 26 RING-RETAINING | 1 | |
| 2744254 | 27 RING-SEAL | 1 | |
| 2746111 | 28 RACE-BEARING | 1 | |
| 2749319 | 29 CARRIER AS-RING | 1 | |
| 1A2223 | DOWEL | 1 | |
| 3802810 | 30 SHIELD AS | 1 | |
| 2776901 | 31 ROTOR-RETARDER | 1 | |
| 2873144 | 32 STUD (M12X1.75X165-MM) | 13 | |
| 2958261 | 33 GEAR (55-TEETH) | 1 | |
| 3752451 | 34 HOUSING AS-TORQUE CONVERTER (INTERMEDIATE) | 1 | |
| 3045103 | 35 STATOR-RETARDER | 1 | |
| 3045104 | 36 STATOR-RETARDER | 1 | |
| 3660683 | 37 MANIFOLD | 1 | |
| 3048981 | 38 PLATE-LIFTING | 1 | |
| 3049042 | 39 HOUSING GP-TORQUE CONVERTER | 1 | |
| 1A2223 | DOWEL | 4 | |
| 5M7937 | DOWEL | 2 | |
| 2656991 | INSERT-THREADED (M16X2-THD) | 12 | |
| 2664188 | INSERT-THREADED (M8X1.25-THD) | 12 | |
| 3380891 | 40 PLATE-INFORMATION (TRANSMISSION) | 1 | |
| 3521944 | 41 GASKET | 1 | |
| 0336036 | 42 SEAL-O-RING | 1 | |
| 0950658 | 43 BOLT-SOCKET HEAD (M10X1.5X70-MM) | 13 | |
| 1729966 | 44 BOLT (M12X1.75X65-MM) | 13 | |
| 1833407 | 45 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1833409 | 46 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 0335853 | SEAL-O-RING | 1 | |
| 6V8197 | 47 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4183 | 48 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4244 | 49 NUT (M12X1.75-THD) | 13 |
