System And Components
418-7978 HOUSING GP-TORQUE CONVERTER -RETARDERS/N PFW575-UP
Group No: 418-7978
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B6161 | 1 LOCK | 1 | |
| 2P8986 | 2 CUP-BEARING | 1 | |
| 2P8987 | 3 CONE-BEARING | 1 | |
| 4H6112 | 4 BREATHER (TORQUE CONVERTER) | 1 | |
| 4H7859 | 5 LOCKNUT-BEARING | 1 | |
| 5P8245 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 5P8347 | 7 BOLT (M8X1.25X70-MM) | 2 | |
| 6V3551 | 8 SEAL-O-RING | 1 | |
| 6V5684 | 9 BOLT (M12X1.75X45-MM) | 7 | |
| 6V5839 | 10 WASHER (11X21X2.5-MM THK) | 14 | |
| 6V5843 | 11 BOLT (M10X1.5X45-MM) | 1 | |
| 4166337 | 12 BEARING | 2 | |
| 4166338 | 13 BEARING-CUP | 2 | |
| 7L9061 | 14 SEAL-O-RING | 2 | |
| 8H7801 | 15 CONE-BEARING | 1 | |
| 8H7803 | 16 CUP-BEARING | 1 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 13 | |
| 1281663 | 18 RING-SEAL | 2 | |
| 1363378 | 19 SEAL-O-RING | 1 | |
| 4591195 | 20 BEARING-THRUST | 1 | |
| 2655834 | 21 MANIFOLD | 1 | |
| 2655840 | 22 GEAR (70-TEETH) | 1 | |
| 2744252 | 23 RING-RETAINING | 1 | |
| 2744254 | 24 RING-SEAL | 1 | |
| 2746111 | 25 RACE-BEARING | 1 | |
| 4190034 | 26 CARRIER AS | 1 | |
| 1A2223 | DOWEL | 1 | |
| 3802810 | 27 SHIELD AS | 1 | |
| 2776901 | 28 ROTOR-RETARDER | 1 | |
| 2873144 | 29 STUD (M12X1.75X165-MM) | 8 | |
| 2958261 | 30 GEAR (55-TEETH) | 1 | |
| 3752451 | 31 HOUSING AS-TORQUE CONVERTER (INTERMEDIATE) | 1 | |
| 3045103 | 32 STATOR-RETARDER | 1 | |
| 3045104 | 33 STATOR-RETARDER | 1 | |
| 3380891 | 34 PLATE-INFORMATION (TRANSMISSION) | 1 | |
| 3521944 | 35 GASKET | 1 | |
| 3660683 | 36 MANIFOLD | 1 | |
| 3632112 | 37 SEAL-LIP TYPE | 1 | |
| 3710888 | 38 HOUSING AS-TORQUE CONVERTER | 1 | |
| 5M7937 | DOWEL | 2 | |
| 2656991 | INSERT-THREADED (M16X2-THD) | 10 | |
| 2664188 | INSERT-THREADED (M8X1.25-THD) | 12 | |
| 0950658 | 39 BOLT-SOCKET HEAD (M10X1.5X70-MM) | 13 | |
| 1729966 | 40 BOLT (M12X1.75X65-MM) | 13 | |
| 1833407 | 41 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V2317 | 42 BOLT (M8X1.25X30-MM) | 2 | |
| 8T4244 | 43 NUT (M12X1.75-THD) | 8 | |
| 8T5092 | 44 BOLT (M12X1.75X150-MM) | 5 | |
| 9M1974 | 45 WASHER-HARD (8.8X16X2-MM THK) | 4 |
