System And Components
352-1010 LINES GP-OILPART OF 352-7627 FILTER GP-FUMES DISPOSAL
Group No: 352-1010 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7233 | 1 GROMMET | 1 | |
| 3489705 | 2 VALVE AS-CHECK | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3511780 | 3 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3521011 | 4 TUBE AS | 1 | |
| 0S0509 | 5 BOLT (3/8-16X0.75-IN) | 1 | |
| 1091145 | 6 CLAMP-HOSE | 2 | |
| 1A4273 | 7 BOLT (5/8-18X1.25-IN) | 1 | |
| 3491209 | 8 CLIP | 1 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5S0003 | 10 NUT (5/16-18-THD) | 1 | |
| 5057426 | 11 ADAPTER AS | 2 | |
| 3717226 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 8T1887 | 12 CLIP (SLOT) | 1 | |
| 8T1888 | 13 CLIP (TAB) | 1 | |
| 5P8247 | 14 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 4231983 | 17 HOSE (12.2-IN) |
