System And Components
7E-4174 VALVE MECHANISM GPJAKE BRAKE
Group No: 7E-4174
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8S1498 | 1 BRACKET-SHAFT | 1 | |
| 7N0550 | 2 WASHER-SPRING | 2 | |
| 9H1113 | 3 RING-RETAINING | 2 | |
| 1B7709 | 4 BOLT (5/8-11X8-IN) | 1 | |
| 2S0736 | WASHER-HARD (17X27X3.5-MM THK) | 1 | |
| 8M4448 | 5 SEAL-O-RING | 1 | |
| 7C7011 | 6 BRACKET-SHAFT | 1 | |
| 5M4606 | 7 DOWEL | 1 | |
| 1L5072 | 8 DOWEL | 1 | |
| 8N3251 | 9 SHAFT-ROCKER ARM | 1 | |
| 6V3508 | 10 PLUG-CUP | 2 | |
| 4B4910 | 11 SPRING | 5 | |
| 9M9886 | 12 WASHER (31.75X19.05X0.08-MM THK) | 13 | |
| 5S5879 | 13 BRACKET-SHAFT | 4 | |
| 9N5980 | 14 ROCKER ARM AS | 6 | |
| 7E4179 | 14A SCREW-ADJUSTMENT | 6 | |
| 1044805 | 14B NUT-SPHERICAL | 6 | |
| 8N3327 | 15 ROCKER ARM GP (INLET) | 6 | |
| 5S5917 | 15A SCREW | 1 | |
| 3S2713 | 15B NUT-FULL (3/8-24-THD) | 1 |
