System And Components
9R-1364 LINES GP-LIFT CYLINDERS/N 5BL1-3294
Group No: 9R-1364
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2114038 | 1 HOSE AS | 2 | |
| 6V9832 | 2 CAP (ORFS) | 2 | |
| 1488327 | 3 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488449 | 4 TEE AS-SWIVEL | 2 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 6V9839 | TEE-SWIVEL | 1 | |
| 1488451 | 5 TEE AS | 2 | |
| 6V8791 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 3 | |
| 8T4136 | 6 BOLT (M10X1.5X25-MM) | 10 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T1887 | 8 CLIP (SLOT) | 12 | |
| 8T1888 | 9 CLIP (TAB) | 12 | |
| 9R3681 | 10 TUBE AS | 1 | |
| 7J9108 | 11 SEAL-O-RING | 8 | |
| 9R3682 | 12 TUBE AS | 1 | |
| 9R3685 | 13 TUBE AS | 1 | |
| 9R3707 | 14 TUBE AS | 1 | |
| 9R4623 | 15 HOSE AS | 4 | |
| 9R5050 | 16 TUBE AS | 2 | |
| 9R5051 | 17 TUBE AS | 2 | |
| 1488388 | 18 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8629 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8T4195 | 19 BOLT (M10X1.5X30-MM) | 2 | |
| 1488322 | 20 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 5P1717 | 21 CLAMP-HOSE | 4 | |
| 9R5049 | 22 PLATE AS | 2 | |
| 9R3669 | 23 PLATE | 1 | |
| 8T0389 | 24 LOCKNUT (M10X1.5-THD) | 2 |
