System And Components
Assembly
100%

136-4364 AXLE GP-FRONTS/N 6GS1-UP

Group No: 136-4364
Part NumberPart NameQty
12385051 AXLE-FRONT1
12501272 PIN1
8G79463 PLATE1
8T93934 BOLT (5/8-11X1.5-IN)1
8T41225 WASHER-HARD (17X32X3.5-MM THK)13
4H94576 WASHER (10-MM THK)1
8T89177 BOLT (1/2-13X1.25-IN)2
8T42238 WASHER-HARD (13.5X25.5X3-MM THK)2
13643839 BRACKET2
1D462910 BOLT (7/8-9X3.5-IN)12
5P824911 WASHER-HARD (24X41.5X4-MM THK)12
5P256612 BOLT (1/2-13X1.5-IN)4
7X058313 WASHER-HARD (17X45X6-MM THK)4
128258414 PAD2
8T687115 BOLT (5/8-11X2.5-IN)12
8G419016 SEAL2
3B848917 FITTING-GREASE (1/8-27 PTF)1
1J647218 RING-RETAINING2
8G418919 BEARING-SELF-ALIGNING1
4M155220 CONE-BEARING2
7X034321 BOLT (5/8-11X1.25-IN)4
100455022 SPINDLE2
9G531523 SEAL GP-DUO-CONE2
2M0344RING-SEALING2
103223724 HUB-IDLER WHEEL2
4E587525 RING (BACKUP)2
1D463926 BOLT (1-8X4-IN)24
5P825027 WASHER (28X49X5-MM THK)24
5M306228 BOLT (3/8-16X0.75-IN)16
8T489629 WASHER-HARD (10.2X18.5X2.5-MM THK)16
4H650730 LOCKNUT2
104537331 CAP GP-HUB2
9U4280PLUG1
1055125GASKET-HUB CAP1
6V191832 LOCKWASHER-BEARING2
107745833 WASHER2
1J475734 CONE-BEARING2
1J286035 CUP-BEARING2
9X223036 PLUG-DRAIN (MAGNETIC)2
3K036037 SEAL-O-RING2
132659838 CUP-BEARING2
195753339 SHIM-TAPERED (0-DEG)2
1957531SHIM-TAPERED (0.1-DEG)2
1106352SHIM-TAPERED (0.2-DEG)2
1106353SHIM-TAPERED (0.3-DEG)2
1106354SHIM-TAPERED (0.4-DEG)2
1106355SHIM-TAPERED (0.5-DEG)2
1106356SHIM-TAPERED (0.6-DEG)2
1106357SHIM-TAPERED (0.7-DEG)2
1106358SHIM-TAPERED (0.8-DEG)2
1123761SHIM-TAPERED (0.9-DEG)2
